CHB150W8系列9-75V输入电源CHB150W8-36S05N CHB150W8-36S48N
详细信息
| | 品牌：CINCON | | 型号：CHB150W8-36S12 CHB150W8-36S24& | | 加工定制：是 | |
| | 输入电压：DC9-75 V | | 输出电压：DC5--48 V | | 输出功率：150 W | |
| | 工作温度：-40--100 ℃ | | | | | |
CHB150W8系列9-75V输入电源CHB150W8-36S12 CHB150W8-36S24
CHB150W8-36S05N CHB150W8-36S15N CHB150W8-36S48N
DC-DC转换器
·150W输出
·砖块大小
·效率92.5％
·远程开/关
·输入欠压保护
·过温保护
·电压/电流保护
Model List
| Part Number |
Input Voltage |
Output Voltage |
Output Current |
No load Input Current |
Efficiency (效率) |
I/O Isolation Voltage |
| CHB150W8-36S12 |
9~75V |
12V |
12.5A |
150mA |
89.5 |
1500VDC |
| CHB150W8-36S15 |
9~75V |
15V |
10A |
150mA |
90 |
1500VDC |
| CHB150W8-36S24 |
9~75V |
24V |
6.25A |
60mA |
89.5 |
1500VDC |
| CHB150W8-36S28 |
9~75V |
28V |
5.35A |
60mA |
90 |
1500VDC |
| CHB150W8-36S48 |
9~75V |
48V |
3.13A |
60mA |
90 |
1500VDC |
| CHB150W8-36S12N |
9~75V |
12V |
12.5A |
150mA |
89.5 |
1500VDC |
| CHB150W8-36S15N |
9~75V |
15V |
10A |
150mA |
90 |
1500VDC |
| CHB150W8-36S24N |
9~75V |
24V |
6.25A |
60mA |
89.5 |
1500VDC |
| CHB150W8-36S28N |
9~75V |
28V |
5.35A |
60mA |
90 |
1500VDC |
| CHB150W8-36S48N |
9~75V |
48V |
3.13A |
60mA |
90 |
1500VDC |
