幸康铁路电源CQB100W-110S05 CQB100W-110S12 CQB100W-110S24
详细信息
| | 品牌：CINCON | | 型号：CQB100W-110S28 CQB100W-110S48 | | 加工定制：是 | |
| | 输入电压：DC43-160 V | | 输出电压：3.3--48 V | | 输出功率：150 W | |
| | 工作温度：-40--105 ℃ | | | | | |
幸康铁路电源模块CQB100W-110S05 CQB100W-110S12 CQB100W-110S24 CQB100W-110S28 CQB100W-110S48
100W DC-DC转换器输入电压43-160VDC
100W输出
效率92％
固定开关频率
4：1输入范围
调节输出
远程开/关
低空载功耗
过温保护
过压/电流保护
连续短路保护
四分之一砖尺寸
Model List
| Part Number |
Input Voltage |
Output Voltage |
Output Current |
No load Input Current |
Efficiency ( 效率) |
I/O Isolation Voltage |
| CQB100W-110S05 |
43~160V |
5V |
20A |
10mA |
91 |
3000VDC |
| CQB100W-110S12 |
43~160V |
12V |
8.4A |
10mA |
92 |
3000VDC |
| CQB100W-110S24 |
43~160V |
24V |
4.2A |
10mA |
89 |
3000VDC |
| CQB100W-110S28 |
43~160V |
28V |
3.6A |
10mA |
88.5 |
3000VDC |
| CQB100W-110S48 |
43~160V |
48V |
2.1A |
10mA |
90 |
3000VDC |
| CQB100W-110S05N |
43~160V |
5V |
20A |
10mA |
91 |
3000VDC |
| CQB100W-110S12N |
43~160V |
12V |
8.4A |
10mA |
92 |
3000VDC |
| CQB100W-110S24N |
43~160V |
24V |
4.2A |
10mA |
89 |
3000VDC |
| CQB100W-110S28N |
43~160V |
28V |
3.6A |
10mA |
88.5 |
3000VDC |
| CQB100W-110S48N |
43~160V |
48V |
2.1A |
10mA |
90 |
3000VDC |
