EC4AW-H6 6000VDC绝缘电压电源模块EC4AW-24S05H6
详细信息
| | 品牌：CINCON | | 加工定制：是 | | 型号：EC4AW-48S05H6，EC4AW-48D12H6 | |
| | 输出电流：8 A | | 输入电压：9-36V,18-72V V | | 输出电压：5V,12V,15V,+/-15V,+/-12V V | |
| | 输出功率：6W W | | 负载调整率：+/-1% | | 显示精度：+/-1% | |
| | 频率范围：250K HZ | | 产品认证：UL,CE,TUV | | | |
EC4AW-H6 6000V绝缘电压电源模块
| 生产商: |
Cincon |
| 产品类别: |
DC-DC转换器 |
| 系列: |
EC4AW-H6 |
| 输入电压: |
9-36, 18-72Vdc |
| 输出电压: |
5, 12, ±12, ±15Vdc |
| 输出功率: |
5-6W |
| 特性: |
*DIP-24封装
*输入/输出电压: 6000Vdc
*持续短路保护
*穏压输出
|
| 型号 |
输入电压 |
输出电压 |
输出电流 |
输入电流 |
效率% |
| Min |
Max |
空载 |
满载 |
(2) |
(3) |
| EC4AW-24S05H6 |
9-36V |
5V |
100mA |
1000mA |
10mA |
260mA |
81 |
80 |
| EC4AW-24S12H6 |
9-36V |
12V |
50mA |
500mA |
10mA |
295mA |
85.5 |
85 |
| EC4AW-24D12H6 |
9-36V |
±12V |
25mA |
±250mA |
15mA |
298mA |
84.5 |
84 |
| EC4AW-24D15H6 |
9-36V |
±15V |
20mA |
±200mA |
15mA |
298mA |
84.5 |
84 |
| EC4AW-48S05H6 |
18-72V |
5V |
100mA |
1000mA |
5mA |
130mA |
81 |
80 |
| EC4AW-48S12H6 |
18-72V |
12V |
50mA |
500mA |
5mA |
149mA |
85 |
84 |
| EC4AW-48D12H6 |
18-72V |
±12V |
25mA |
±250mA |
8mA |
150mA |
84 |
83 |
| EC4AW-48D12H6 |
18-72V |
±15V |
20mA |
±200mA |
8mA |
149mA |
85 |
84 |
