URED20W系列非PCB板安装DC-DC模块电源 URED20-24S3P3W
详细信息
| | 品牌：P-DUKE | | 加工定制：是 | | 型号：URED20-110S05W URED20-110D15W | |
| | 输出电流：5 A | | 输入电压：9-36V,18-75V,43-160V V | | 输出电压：3.3V--24V V | |
| | 输出功率：20 W | | 负载调整率：+/-1% | | 显示精度：+-1% | |
| | 频率范围：300K HZ | | 产品认证：CE,UL,TUV | | | |
URED20W系列非PCB板安装DC-DC模块电源 URED20-24S3P3W URED20-24S05W URED20-24S12W
产品
■无需小负载
■2250vdc输入到输出绝缘
■底盘安装型DC / DC转换器的应用
■用于输入和输出连接的螺丝端子
■内部输入保险丝保护
■内部输出LED指示灯
| 產品型號 |
輸入範圍 |
輸出電壓 |
| URED20-48S15W |
18 ~ 75 VDC |
15 VDC / 1330 mA |
| URED20-48D12W |
18 ~ 75 VDC |
±12 VDC / ± 833 mA |
| URED20-48D15W |
18 ~ 75 VDC |
±15 VDC / ± 667 mA |
| URED20-110S3P3W |
43 ~ 160 VDC |
3.3 VDC / 4500 mA |
| URED20-110S05W |
43 ~ 160 VDC |
5 VDC / 4000 mA |
| URED20-110S12W |
43 ~ 160 VDC |
12 VDC / 1670 mA |
| URED20-110S15W |
43 ~ 160 VDC |
15 VDC / 1330 mA |
| URED20-110D12W |
43 ~ 160 VDC |
±12 VDC / ± 833 mA |
| URED20-110D15W |
43 ~ 160 VDC |
±15 VDC / ± 667 mA |
| URED20-24S3P3W |
9 ~ 36 VDC |
3.3 VDC / 4500 mA |
| URED20-24S05W |
9 ~ 36 VDC |
5 VDC / 4000 mA |
| URED20-24S12W |
9 ~ 36 VDC |
12 VDC / 1670 mA |
| URED20-24S15W |
9 ~ 36 VDC |
15 VDC / 1330 mA |
| URED20-24D12W |
9 ~ 36 VDC |
±12 VDC / ± 833 mA |
| URED20-24D15W |
9 ~ 36 VDC |
±15 VDC / ± 667 mA |
| URED20-48S3P3W |
18 ~ 75 VDC |
3.3 VDC / 4500 mA |
| URED20-48S05W |
18 ~ 75 VDC |
5 VDC / 4000 mA |
| URED20-48S12W |
18 ~ 75 VDC |
12 VDC / 1670 mA |
