TDK-LAMBDADC/DC电源CCG15-24-03S CCG15-24-05S CCG15-24-12S
详细信息
| | 品牌：TDK-LAMBDA | | 加工定制：是 | | 型号：CCG15-24-15S CCG15-48-03S | |
| | 输出电流：6 A | | 输入电压：9～36VDC/18-75vdc V | | 输出电压：3.3--48 V | |
| | 输出功率：15--30 W | | 负载调整率：+/-1$ | | 产品认证：ul ce | |
TDK-LAMBDA DC/DC电源CCG15-24-03S CCG15-24-05S CCG15-24-12S CCG15-24-15S CCG15-48-03S
特征
紧凑尺寸：30瓦输出，从1×1英寸的足迹
*在行业中小的，比以前的同类产品少50%左右。
输入电压范围：9至36伏直流电压和18至76 VDC输入类型可用
*相当于以前同类产品输入电压范围的两倍
六面隔音结构：除金属外壳外，PCB铜箔提供底部。
效率：91%（ccg30-48-15s）
操作环境温度范围宽：在40至85度的环境中使用。
1500伏直流耐压（1分钟）
| Type |
CCG15-24 |
CCG15-48 |
| Input voltage |
9～36VDC |
18～76VDC |
| Model name |
CCG15-24-03S |
CCG15-24-05S |
CCG15-24-12S |
CCG15-24-15S |
CCG15-48-03S |
CCG15-48-05S |
CCG15-48-12S |
CCG15-48-15S |
| Output voltage |
3.3V |
5V |
12V |
15V |
3.3V |
5V |
12V |
15V |
| Efficiency(typ) |
85% |
87% |
88% |
88% |
85% |
87% |
88% |
88% |
| Output current |
4.0A |
3.0A |
1.3A |
1.0A |
4.0A |
3.0A |
1.3A |
1.0A |
| Output power |
13.2W |
15.0W |
15.6W |
15.0W |
13.2W |
15.0W |
15.6W |
15.0W |
| Output voltage Range |
-10～+10% |
| Operating temperature |
-40～+85℃ |
| Withstand voltage |
Input - Output：1500VDC 1min, Input/Output - Case：1000VDC 1min |
| Safety standards |
UL60950-1, CSA60950-1, EN60950-1 |
| Warranty |
5 years |
| Type |
CCG30-24 |
CCG30-48 |
| Input voltage |
9～36VDC |
18～76VDC |
| Model name |
CCG30-24-03S |
CCG30-24-05S |
CCG30-24-12S |
CCG30-24-15S |
CCG30-48-03S |
CCG30-48-05S |
CCG30-48-12S |
CCG30-48-15S |
| Output voltage |
3.3V |
5V |
12V |
15V |
3.3V |
5V |
12V |
15V |
| Efficiency(typ) |
86% |
89% |
89% |
89% |
87% |
90% |
90% |
91% |
| Output current |
7.0A |
6.0A |
2.5A |
2.0A |
7.0A |
6.0A |
2.5A |
2.0A |
| Output power |
23.1W |
30.0W |
30.0W |
30.0W |
23.1W |
30.0W |
30.0W |
30.0W |
| Output voltage Range |
-10～+10% |
| Operating temperature |
-40～+85℃ |
| Withstand voltage |
Input - Output：1500VDC 1min, Input/Output - Case：1000VDC 1min |
| Safety standards |
|
| Warranty |
5 years |
As for the mention contents of this page, understand beforehand because it sometimes changes.
