日本TDK-LAMBDA开关电源SWS600L-24 SWS600L-60 SWS600L-12
详细信息
| | 品牌：TDK-LAMBDA | | 类型：AC/DC电源 | | 输入电压：AC90-264V V | |
| | 输出功率：600 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：半桥式 | |
| | 输出电压：3.3V,-60 V | | 工作效率：91 % | | 型号：SWS600L-24 SWS600L12 SWS600L-5 | |
日本TDK-LAMBDA开关电源SWS600L-24 SWS600L-60 SWS600L-12 SWS600L-5 SWS600L-3 SWS600L-15 SWS600L-48
低轮廓:纤细的设计与薄的61mm。
工作温度范围(-20°C ~ + 74°C)
温度控制风扇
减少噪声
| Model |
SWS
600L-3 |
SWS
600L-5 |
SWS
600L-12 |
SWS
600L-15 |
SWS
600L-24 |
SWS
600L-36 |
SWS
600L-48 |
SWS
600L-60 |
| Input Voltage Range |
AC85 to 265V (47-63Hz) or DC120 to 350V |
Maximum Output Power
(Peak Power) |
396W |
600W |
636W |
645W |
648(744)W |
648W |
624(720)W |
600W |
| Normal Output Voltage |
3.3V |
5V |
12V |
15V |
24V |
36V |
48V |
60V |
| Output Voltage Range |
2.64-
3.96V |
4.0-
6.0V |
9.6-
14.4V |
12.0-
19.5V |
19.2-
28.8V |
28.8-
43.2V |
38.4-
56.0V |
48.0-
66.0V |
| Operating Temperature |
-20 to +74C ( -20 to +50 : 100%, +74 :50% ) |
| Safety |
|
| EMI |
|
| Immunity |
Designed to meet EN61000-4-2 (Level 2, 3), -3 (Level 3),
-4 (Level 3), -5 (Level 3, 4), -6 (Level 3), -8 (Level 4), -11 |
| Weight |
1.6kg |
| Dimension (mm) |
120 x 61 x 190 |
Product lineup
| Output Voltage |
600W |
| Output Current |
Model |
| 3.3V |
120A |
SWS600L-3 |
| 5V |
120A |
SWS600L-5 |
| 12V |
53A |
SWS600L-12 |
| 15V |
43A |
SWS600L-15 |
| 24V |
27(31)A |
SWS600L-24 |
| 36V |
18A |
SWS600L-36 |
| 48V |
13(15)A |
SWS600L-48 |
| 60V |
10A |
SWS600L-60 |
As for the mention contents of this page, understand beforehand because it sometimes changes.
