TDK-LAMBDA开关电源SWS1000L-24 SWS1000L-60 SWS1000L-12
详细信息
| | 品牌：TDK-LAMBDA | | 类型：AC/DC电源 | | 输入电压：AC90-264 V | |
| | 输出功率：1000 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：半桥式 | |
| | 输出电压：3.3--60 V | | 工作效率：89 % | | 型号：SWS1000L-48 SWS1000L-15 | |
日本TDK-LAMBDA开关电源SWS1000L-24 SWS1000L-60 SWS1000L-12 SWS1000L-5 SWS1000L-3 SWS1000L-15 SWS1000L-48
低轮廓:纤细的设计与薄的61mm。
工作温度范围(-20°C ~ + 74°C)
温度控制风扇
减少噪声
| Model |
SWS
1000L-3 |
SWS
1000L-5 |
SWS
1000L-12 |
SWS
1000L-15 |
SWS
1000L-24 |
SWS
1000L-36 |
SWS
1000L-48 |
SWS
1000L-60 |
| Input Voltage Range |
AC85 to 265V (47-63Hz) or DC120 to 350V |
Maximum Output Power
(Peak Power) |
660W |
1000W |
1056W |
1050W |
1056(1224)W |
1044W |
1056(1200)W |
1020W |
| Normal Output Voltage |
3.3V |
5V |
12V |
15V |
24V |
36V |
48V |
60V |
| Output Voltage Range |
2.64-3.96V |
4.0-6.0V |
9.6-14.4V |
12.0-19.5V |
19.2-28.8V |
28.8-43.2V |
38.4-56.0V |
48.0-66.0V |
| Operating Temperature |
-20 to +74°C ( -20 to +50 : 100%, +74 :50% ) |
| Safety |
Approved by UL60950-1,CSA60950-1, EN60950-1, EN50178, UL60601-1, EN60601-1
CSA-C22.2 No.601.1-M90 Designed to meet DENAN, EN61010-1 |
| EMI |
Designed to meet VCCI-B, FCC-B,EN55011/EN55022-B |
| Immunity |
Designed to meet EN61000-4-2 (Level 2, 3), -3 (Level 3),
-4 (Level 3), -5 (Level 3, 4), -6 (Level 3), -8 (Level 4), -11 |
| Weight |
2.3kg |
| Dimension (mm) |
150 x 61 x 240 |
Product lineup
| Output Voltage |
1000W |
| Output Current |
Model |
| 3.3V |
200A |
SWS1000L-3 |
| 5V |
200A |
SWS1000L-5 |
| 12V |
88A |
SWS1000L-12 |
| 15V |
70A |
SWS1000L-15 |
| 24V |
44(51)A |
SWS1000L-24 |
| 36V |
29A |
SWS1000L-36 |
| 48V |
22(25)A |
SWS1000L-48 |
| 60V |
17A |
SWS1000L-60 |
As for the mention contents of this page, understand beforehand because it sometimes changes.
