TDK-LAMBDA轨道交通电源DC110V输入 CN50A24-12 CN30A110-12
详细信息
| | 品牌：TDK-LAMBDA | | 加工定制：是 | | 型号：CN200A110-24 CN100A24-12 | |
| | 输出电流：15 A | | 输入电压：60-160Vdc和14.4 - 36Vdc V | | 输出电压：5V,12V,24V V | |
| | 输出功率：30W,50W,100W,200W W | | 产品认证：UL CE | | | |
TDK-LAMBDA轨道交通电源DC110V输入 CN50A24-12 CN30A110-12 CN100A24-12 CN200A110-24
以60 - 160Vdc或14.4 - 36Vdc的输入为特点，CN-A适合IEC61373的严格冲击和振动要求，以及日本等效标准JIS e4031。涂层选项允许产品适合EN50155。功率运行在所有转换器是在-40 + 100°C基板温度。除了半砖200W，都有四分之一砖的占地面积，并能承受3kVac绝缘电压。
特性
60-160Vdc和14.4 - 36Vdc输入范围。
iec61373震动和震动。
底座冷却
功率在100°C的底座
五年保修
| Part number |
Power (W) |
Output info |
Construction |
|
| CN30A110-5 |
30 |
5V / 6A |
Quarter Brick |
|
| CN50A110-5 |
50 |
5V / 10A |
Quarter Brick |
|
| CN50A24-5 |
50 |
5V / 10A |
Quarter Brick |
|
| CN100A110-5 |
100 |
5V / 20A |
Quarter Brick |
|
| CN100A24-5 |
100 |
5V / 20A |
Quarter Brick |
|
| CN200A110-5 |
200 |
5V / 40A |
Half Brick |
|
| CN30A110-12 |
30 |
12V / 2.5A |
Quarter Brick |
|
| CN50A110-12 |
50.4 |
12V / 4.2A |
Quarter Brick |
|
| CN50A24-12 |
50.4 |
12V / 4.2A |
Quarter Brick |
|
| CN100A110-12 |
100.8 |
12V / 8.4A |
Quarter Brick |
|
| CN100A24-12 |
100.8 |
12V / 8.4A |
Quarter Brick |
|
| CN200A110-12 |
200 |
12V / 16.7A |
Half Brick |
|
| CN30A110-15 |
30 |
15V / 2A |
Quarter Brick |
|
| CN50A110-15 |
51 |
15V / 3.4A |
Quarter Brick |
|
| CN100A110-15 |
100.5 |
15V / 6.7A |
Quarter Brick |
|
| CN200A110-15 |
200 |
15V / 13.4A |
Half Brick |
|
| CN30A110-24 |
31.2 |
24V / 1.3A |
Quarter Brick |
|
| CN50A110-24 |
50.4 |
24V / 2.1A |
Quarter Brick |
|
| CN50A24-24 |
50.4 |
24V / 2.1A |
Quarter Brick |
|
| CN100A110-24 |
100.8 |
24V / 4.2A |
Quarter Brick |
|
| CN100A24-24 |
100.8 |
24V / 4.2A |
Quarter Brick |
|
| CN200A110-24 |
200 |
24V / 8.4A |
Half Brick |
|
