CINCON电源EC7BW 20W系列EC7BW-24S05 EC7BW-24S12 EC7BW-24S15
详细信息
| | 品牌：CINCON | | 加工定制：是 | | 型号：EC7BW-24D12 EC7BW-24D15 | |
| | 输出电流：6 A | | 输入电压：DC9-36V/18-75V V | | 输出电压：3.3V,5V,12V,15V V | |
| | 输出功率：20 W | | 产品认证：UL CE TUV | | | |
模块电源CINCON EC7BW 20W
系列EC7BW-24S05 EC7BW-24S12 EC7BW-24S15 EC7BW-24S33 EC7BW-24D05 EC7BW-24D12 EC7BW-24D15
EC7BW
20 WATT 4
：1
输入
DC-DC
转换器
20W
输出
4
：1
输入范围
效率90
％
连续短路保护
Pi
输入滤波器
Model
Number |
Input |
Output |
Output Current |
Input Current |
效率 EFF |
| Min |
Max |
No Load |
Full Load |
| EC7BW-24S33 |
9-36V |
3.3V |
0mA |
5500mA |
55mA |
869mA |
87 |
| EC7BW-24S05 |
9-36V |
5V |
0mA |
4000mA |
55mA |
926mA |
90 |
| EC7BW-24S12 |
9-36V |
12V |
0mA |
1670mA |
55mA |
928mA |
90 |
| EC7BW-24S15 |
9-36V |
15V |
0mA |
1330mA |
55mA |
924mA |
90 |
| EC7BW-24D05 |
9-36V |
+/-5V |
0mA |
+/-2000mA |
70mA |
937mA |
89 |
| EC7BW-24D12 |
9-36V |
+/-12V |
0mA |
+/-835mA |
35mA |
947mA |
88 |
| EC7BW-24D15 |
9-36V |
+/-15V |
0mA |
+/-666mA |
35mA |
947mA |
88 |
| EC7BW-48S33 |
18-75V |
3.3V |
0mA |
5500mA |
25mA |
430mA |
88 |
| EC7BW-48S05 |
18-75V |
5V |
0mA |
4000mA |
25mA |
463mA |
90 |
| EC7BW-48S12 |
18-75V |
12V |
0mA |
1670mA |
25mA |
464mA |
90 |
| EC7BW-48S15 |
18-75V |
15V |
0mA |
1330mA |
25mA |
462mA |
90 |
| EC7BW-48D05 |
18-75V |
+/-5V |
0mA |
+/-2000mA |
35mA |
468mA |
89 |
| EC7BW-48D12 |
18-75V |
+/-12V |
0mA |
+/-835mA |
25mA |
474mA |
88 |
| EC7BW-48D15 |
18-75V |
+/-15V |
0mA |
+/-666mA |
25mA |
474mA |
88 |
Dimensions(Inch)
2.00x1.00x0.40(DIP) CINCON电源EC7BW 20W系列EC7BW-24S05 EC7BW-24S12 EC7BW-24S15
