TRACO POWER工控电源模块TMR2-0511WISM TMR2-0512WISM
详细信息
| | 品牌：TRACOPOWER | | 型号：TMR2-0513WISM TMR2-0515WI | | 加工定制：是 | |
| | 输入电压：4.5-75 V | | 输出电压：3.3--24 V | | 输出功率：2 W | |
| | 工作温度：-40--85 ℃ | | | | | |
TRACO POWER工控电源模块TMR2-0511WISM TMR2-0512WISM TMR2-0513WISM TMR2-0515WISM
TMR 2WISM系列是一组2瓦SMD DC / DC转换器。 它们在负荷或达80°C的环境温度下工作温度70°C，负载降额为50％。 1,500 VDC I / O绝缘电压，外部开/关和短路保护，当空间有限时，它们涵盖了的应用。 转换器的输入设计用于电压范围（4：1），不需要小负载。
特征
4：1输入：4.5-12,9-36和18-75 VDC
I / O绝缘1'500 VDC
工作温度范围为-40°C至+ 80°C
防止短路和过载
远程开/关
3年产品保修
Models
| Order code |
Input |
Output |
| TMR2-0511WISM |
4.5 - 12 VDC |
5 VDC / 400 mA |
| TMR2-0512WISM |
4.5 - 12 VDC |
12 VDC / 167 mA |
| TMR2-0513WISM |
4.5 - 12 VDC |
15 VDC / 134 mA |
| TMR2-0515WISM |
4.5 - 12 VDC |
24 VDC / 83 mA |
| TMR2-0522WISM |
4.5 - 12 VDC |
12 VDC / 83 mA | -12 VDC / 83 mA |
| TMR2-0523WISM |
4.5 - 12 VDC |
15 VDC / 67 mA | -15 VDC / 67 mA |
| TMR2-2411WISM |
9 - 36 VDC |
5 VDC / 400 mA |
| TMR2-2412WISM |
9 - 36 VDC |
12 VDC / 167 mA |
| TMR2-2413WISM |
9 - 36 VDC |
15 VDC / 134 mA |
| TMR2-2415WISM |
9 - 36 VDC |
24 VDC / 83 mA |
| TMR2-2422WISM |
9 - 36 VDC |
12 VDC / 83 mA | -12 VDC / 83 mA |
| TMR2-2423WISM |
9 - 36 VDC |
15 VDC / 67 mA | -15 VDC / 67 mA |
| TMR2-4811WISM |
18 - 75 VDC |
5 VDC / 400 mA |
| TMR2-4812WISM |
18 - 75 VDC |
12 VDC / 167 mA |
| TMR2-4813WISM |
18 - 75 VDC |
15 VDC / 134 mA |
| TMR2-4815WISM |
18 - 75 VDC |
24 VDC / 83 mA |
| TMR2-4822WISM |
18 - 75 VDC |
12 VDC / 83 mA | -12 VDC / 83 mA |
| TMR2-4823WISM |
18 - 75 VDC |
15 VDC / 67 mA | -15 VDC / 67 mA |
