20W DC/DC电源EC4SBW-24S33 EC4SBW-24D12 EC4SBW-24D15
详细信息
| | 品牌：CINCON | | 加工定制：是 | | 型号：EC4SBW-48S15 EC4SBW-48S33 | |
| | 输出电流：6 A | | 输入电压：DC9-36V/18-75V V | | 输出电压：3.3--15V V | |
| | 输出功率：20 W | | | | | |
EC4SBW
系列20W CINOCN DC/DC
电源模块EC4SBW-24S33 EC4SBW-24D12 EC4SBW-24D15 EC4SBW-48S15 EC4SBW-48S33
20
瓦特4
：1
输入
DC-DC
转换器
20W
输出
4
：1
输入范围
效率90.5
％
远程开/
关
输入欠压保护
连续短路保护
内部没有钽电容器
Model
Number |
Input |
Output |
Output Current |
Input Current |
效率 EFF |
| Min |
Max |
No Load |
Full Load |
| EC4SBW-24S33 |
9-36V |
3.3V |
0mA |
4500mA |
10mA |
699mA |
88.5 |
| EC4SBW-24S05 |
9-36V |
5V |
0mA |
4000mA |
10mA |
920mA |
90.5 |
| EC4SBW-24S12 |
9-36V |
12V |
0mA |
1670mA |
10mA |
938mA |
89 |
| EC4SBW-24S15 |
9-36V |
15V |
0mA |
1330mA |
10mA |
933mA |
89 |
| EC4SBW-24D12 |
9-36V |
±12V |
0mA |
±830mA |
10mA |
938mA |
88.5 |
| EC4SBW-24D15 |
9-36V |
±15V |
0mA |
±660mA |
10mA |
926mA |
89 |
| EC4SBW-48S33 |
18-75V |
3.3V |
0mA |
4500mA |
8mA |
349mA |
88.5 |
| EC4SBW-48S05 |
18-75V |
5V |
0mA |
4000mA |
8mA |
460mA |
90.5 |
| EC4SBW-48S12 |
18-75V |
12V |
0mA |
1670mA |
8mA |
466mA |
89.5 |
| EC4SBW-48S15 |
18-75V |
15V |
0mA |
1330mA |
8mA |
467mA |
89 |
| EC4SBW-48D12 |
18-75V |
±12V |
0mA |
±830mA |
8mA |
469mA |
88.5 |
| EC4SBW-48D15 |
18-75V |
±15V |
0mA |
±660mA |
8mA |
466mA |
88.5 |
