30W电源转换器EC5SBW-48D12 EC5SBW-48D15 EC5SBW-48S05
详细信息
| | 品牌：CINCON | | 加工定制：是 | | 型号：EC5SBW-48S12， EC5SBW-48S33 | |
| | 输入电压：DC9-36V/18-75V V | | 输出电压：3.3--15V V | | 输出功率：30 W | |
幸康EC5SBW系列30W DC/DC转换器EC5SBW-48D12 EC5SBW-48D15 EC5SBW-48S05 EC5SBW-48S33 EC5SBW-48S12
30W输出
4：1输入范围
效率90％
远程打开/关闭
输入欠压保护
连续短路保护
无钽电容符号
Model
Number |
Input |
Output |
Output Current |
Input Current |
效率 EFF |
| Min |
Max |
No Load |
Full Load |
| EC5SBW-24S33 |
9-36V |
3.3V |
0mA |
7000mA |
10mA |
1119mA |
88 |
| EC5SBW-24S05 |
9-36V |
5V |
0mA |
6000mA |
10mA |
1404mA |
90 |
| EC5SBW-24S12 |
9-36V |
12V |
0mA |
2500mA |
10mA |
1404mA |
89 |
| EC5SBW-24S15 |
9-36V |
15V |
0mA |
2000mA |
10mA |
1404mA |
89 |
| EC5SBW-24D12 |
9-36V |
+/-12V |
0mA |
+/-1250mA |
10mA |
1404mA |
88 |
| EC5SBW-24D15 |
9-36V |
+/-15V |
0mA |
+/-1000mA |
10mA |
1404mA |
88 |
| EC5SBW-48S33 |
18-75V |
3.3V |
0mA |
7000mA |
8mA |
553mA |
88 |
| EC5SBW-48S05 |
18-75V |
5V |
0mA |
6000mA |
8mA |
694mA |
90 |
| EC5SBW-48S12 |
18-75V |
12V |
0mA |
2500mA |
8mA |
694mA |
89 |
| EC5SBW-48S15 |
18-75V |
15V |
0mA |
2000mA |
8mA |
694mA |
89 |
| EC5SBW-48D12 |
18-75V |
+/-12V |
0mA |
+/-1250mA |
8mA |
694mA |
88 |
| EC5SBW-48D15 |
18-75V |
+/-15V |
0mA |
+/-1000mA |
8mA |
694mA |
89 |
