10W稳压电源EC2SBW-24S12 EC2SBW-24D12 EC2SBW-24S15
详细信息
| | 品牌：CINCON | | 加工定制：是 | | 型号：EC2SBW-48D12 EC2SBW-24S33 | |
| | 输出电流：3 A | | 输入电压：DC9-36V/18-75V V | | 输出电压：3.3--15V V | |
| | 输出功率：10 W | | | | | |
EC2SBW系列10W稳压电源EC2SBW-24S12 EC2SBW-24D12 EC2SBW-24S15 EC2SBW-48D12 EC2SBW-24S33
10瓦特4：1输入
DC-DC转换器
10W输出
4：1输入范围
效率86％
远程打开/关闭
输入欠压保护
连续短路保护
Model
Number |
Input |
Output |
Output Current |
Input Current |
效率 EFF |
| Min |
Max |
No Load |
Full Load |
| EC2SBW-24S33 |
9-36V |
3.3V |
0mA |
2500mA |
5mA |
425mA |
81 |
| EC2SBW-24S05 |
9-36V |
5V |
0mA |
2000mA |
5mA |
496mA |
84 |
| EC2SBW-24S12 |
9-36V |
12V |
0mA |
835mA |
10mA |
486mA |
86 |
| EC2SBW-24S15 |
9-36V |
15V |
0mA |
666mA |
10mA |
486mA |
86 |
| EC2SBW-24D05 |
9-36V |
+/-5V |
0mA |
+/-1000mA |
10mA |
496mA |
84 |
| EC2SBW-24D12 |
9-36V |
+/-12V |
0mA |
+/-416mA |
10mA |
486mA |
86 |
| EC2SBW-24D15 |
9-36V |
+/-15V |
0mA |
+/-333mA |
10mA |
486mA |
86 |
| EC2SBW-48S33 |
18-75V |
3.3V |
0mA |
2500mA |
5mA |
210mA |
82 |
| EC2SBW-48S05 |
18-75V |
5V |
0mA |
2000mA |
5mA |
248mA |
84 |
| EC2SBW-48S12 |
18-75V |
12V |
0mA |
835mA |
5mA |
243mA |
86 |
| EC2SBW-48S15 |
18-75V |
15V |
0mA |
666mA |
5mA |
243mA |
86 |
| EC2SBW-48D05 |
18-75V |
+/-5V |
0mA |
+/-1000mA |
5mA |
248mA |
84 |
| EC2SBW-48D12 |
18-75V |
+/-12V |
0mA |
+/-416mA |
8mA |
243mA |
86 |
| EC2SBW-48D15 |
18-75V |
+/-15V |
0mA |
+/-333mA |
8mA |
243mA |
86 |
