CHB150W直流电源CHB150W-24S05 CHB150W-24S28 CHB150W-24S24
详细信息
| | 品牌：CINCON | | 型号：CHB150W-24S15 | | 加工定制：是 | |
| | 输入电压：DC9-36V/18-75 V | | 输出电压：DC3.3--48 V | | 输出功率：150 W | |
| | 工作温度：-40--100 ℃ | | | | | |
CINCON CHB150W直流电源模块CHB150W-24S05 CHB150W-24S28 CHB150W-24S24 CHB150W-24S15
99到150 WATT 4：1 INPUT
DC-DC转换器
·99-150W输出
·砖块大小
·规定输出
·效率91％
·远程开/关
·过温保护
·过电压/电流保护
·连续短路保护
Model
Number |
Input |
Output |
Output Current |
Input Current |
效率 EFF |
| Min |
Max |
No Load |
Full Load |
| CHB150W-24S3V3 |
9-36V |
3.3V |
0mA |
30A |
200mA |
4741mA |
87 |
| CHB150W-24S05 |
9-36V |
5V |
0mA |
30A |
200mA |
7184mA |
87 |
| CHB150W-24S12 |
9-36V |
12V |
0mA |
12.5A |
100mA |
7102mA |
88 |
| CHB150W-24S15 |
9-36V |
15V |
0mA |
10A |
100mA |
7184mA |
87 |
| CHB150W-24S24 |
9-36V |
24V |
0mA |
6.5A |
100mA |
7386mA |
88 |
| CHB150W-24S28 |
9-36V |
28V |
0mA |
5.4A |
100mA |
7325mA |
86 |
| CHB150W-24S48 |
9-36V |
48V |
0mA |
3.12A |
200mA |
7428mA |
84 |
| CHB150W-48S3V3 |
18-75V |
3.3V |
0mA |
30A |
100mA |
2344mA |
88 |
| CHB150W-48S05 |
18-75V |
5V |
0mA |
30A |
100mA |
3472mA |
80 |
| CHB150W-48S12 |
18-75V |
12V |
0mA |
12.5A |
50mA |
3434mA |
91 |
| CHB150W-48S15 |
18-75V |
15V |
0mA |
10A |
50mA |
3472mA |
90 |
| CHB150W-48S24 |
18-75V |
24V |
0mA |
6.5A |
50mA |
3611mA |
90 |
| CHB150W-48S28 |
18-75V |
28V |
0mA |
5.4A |
50mA |
3580mA |
88 |
| CHB150W-48S48 |
18-75V |
48V |
0mA |
3.12A |
100mA |
3633mA |
86 |
