CINCONAC/DC模块电源CFM61W系列
详细信息
| | 品牌：CINCON | | 加工定制：是 | | 类型：开关式直流稳压器 | |
| | 输出电流：15 A | | 输入电压：24 V | | 输出电压：36 V | |
| | 输出功率：50 W | | 频率范围：50-70 | | 工作温度：45 ℃ | |
| | 产品认证：SOD | | 型号：CFM61S050 CFM61S050-E CFM61S05 | | | |
CINCON AC/DC模块电源CFM61W系列CFM61S050-E CFM61S240-E CFM61S120-E
通用输入90~264VAC
效率90％
连续短路保护
过压保护
峰值负载（额定电流的2倍）
Model List
| Part Number |
Power (Watts) |
Input Voltage |
Output Voltage |
Output Current |
Efficiency (效率) |
Operating Altitude |
Operating Temperature |
| CFM61S050 |
40W |
90-264 |
5V |
8.0A |
86% |
5000m |
-30°C ~ 70°C |
| CFM61S050-E |
40W |
90-264 |
5V |
8.0A |
86% |
5000m |
-30°C ~ 70°C |
| CFM61S050 PL |
40W |
90-264 |
5V |
8.0A |
86% |
5000m |
-30°C ~ 70°C |
| CFM61S050-E PL |
40W |
90-264 |
5V |
8.0A |
86% |
5000m |
-30°C ~ 70°C |
| CFM61S050-T |
40W |
90-264 |
5V |
8.0A |
86% |
5000m |
-30°C ~ 70°C |
| CFM61S360 |
60.12W |
90-264 |
36V |
1.67A |
89% |
5000m |
-30°C ~ 70°C |
