ADA600F系列稳压电源ADA600F-24 ADA600F-48
详细信息
| | 品牌：COSEL | | 加工定制：是 | | 类型：开关式直流稳压器 | |
| | 输出电流：30 A | | 输入电压：12 V | | 输出电压：24 V | |
| | 输出功率：40 W | | 频率范围：50-70 | | 工作温度：40 ℃ | |
| | 产品认证：SOP | | 型号：ADA600F-24 ADA600F-48 ADA600F- | | | |
ADA600F系列稳压电源ADA600F-24 ADA600F-48 ADA600F-36 ADA600F-30
•功率和峰值功率。
•用风扇供电(可选)
•并行操作/主从操作/N+1冗余(可选)
•谐波衰减器(符合IEC61000-3-2)
•通用输入电压(AC85 - 264V)
•可选:远程开/关,警报
•电流
•DIN导轨(35mm)可选。
Rated Input：AC85 - 264V 1Φ
Rated Output Wattage：600W
Output Voltage：24V,30V,36V,48V
Product Line-up
| Product Name |
Output Wattage |
Output Voltage･Current |
| ADA600F-24 |
336W (Peak: 600W) ACIN 100V Convection Cooling
504W (Peak: 600W) ACIN 100V Forced Air Cooling
360W (Peak: 744W) ACIN 200V Convection Cooling
600W (Peak: 744W) ACIN 200V Forced Air Cooling |
24V 14A (Peak :25A) ACIN 100V Convection Cooling
24V 21A (Peak :25A) ACIN 100V Forced Air Cooling
24V 15A (Peak :31A) ACIN 200V Convection Cooling
24V 25A (Peak :31A) ACIN 200V Forced Air Cooling |
| ADA600F-30 |
330W (Peak: 600W) ACIN 100V Convection Cooling
495W (Peak: 600W) ACIN 100V Forced Air Cooling
360W (Peak: 735W) ACIN 200V Convection Cooling
600W (Peak: 735W) ACIN 200V Forced Air Cooling |
30V 11A (Peak :20A) ACIN 100V Convection Cooling
30V 16.5A (Peak :20A) ACIN 100V Forced Air Cooling
30V 12A (Peak :24.5A) ACIN 200V Convection Cooling
30V 20A (Peak :24.5A) ACIN 200V Forced Air Cooling |
| ADA600F-36 |
324W (Peak: 594W) ACIN 100V Convection Cooling
504W (Peak: 594W) ACIN 100V Forced Air Cooling
360W (Peak: 738W) ACIN 200V Convection Cooling
594W (Peak: 738W) ACIN 200V Forced Air Cooling |
36V 9A (Peak :16.5A) ACIN 100V Convection Cooling
36V 14A (Peak :16.5A) ACIN 100V Forced Air Cooling
36V 10A (Peak :20.5A) ACIN 200V Convection Cooling
36V 16.5A (Peak :20.5A) ACIN 200V Forced Air Cooling |
| ADA600F-48 |
312W (Peak: 600W) ACIN 100V Convection Cooling
504W (Peak: 600W) ACIN 100V Forced Air Cooling
336W (Peak: 744W) ACIN 200V Convection Cooling
600W (Peak: 744W) ACIN 200V Forced Air Cooling |
48V 6.5A (Peak :12.5A) ACIN 100V Convection Cooling
48V 10.5A (Peak :12.5A) ACIN 100V Forced Air Cooling
48V 7A (Peak :15.5A) ACIN 200V Convection Cooling
48V 12.5A (Peak :15.5A) ACIN 200V Forced Air Cooling |
