3W电源转换器RDL03-48S05W RDL03-48S12W RDL03-48S24W
详细信息
| | 品牌：P-DUKE | | 加工定制：是 | | 类型：开关式直流稳压器 | |
| | 输出电流：30 A | | 输入电压：14 V | | 输出电压：25 V | |
| | 输出功率：45 W | | 频率范围：50-70 | | 工作温度：40 ℃ | |
| | 产品认证：SOP | | 型号：RDL03-24S3P3W RDL03-24S05W RDL | | | |
台湾3W博大电源转换器RDL03-48S05W RDL03-48S12W RDL03-48S24W
特征
■3W输出功率
■3000VDC的绝缘电压
■小尺寸和薄型SIP8封装0.86x 0.36x 0.44英寸
■集成UVP，OCP，SCP
■无需小负载
| Model No |
Input Range |
Output Range |
| RDL03-24S3P3W |
9 ~ 36 VDC |
3.3 VDC / 0.7 A |
| RDL03-24S05W |
9 ~ 36 VDC |
5 VDC / 0.6 A |
| RDL03-24S09W |
9 ~ 36 VDC |
9 VDC / 0.333 A |
| RDL03-24S12W |
9 ~ 36 VDC |
12 VDC / 0.25 A |
| RDL03-24S15W |
9 ~ 36 VDC |
15 VDC / 0.2 A |
| RDL03-24S24W |
9 ~ 36 VDC |
24 VDC / 0.125 A |
| RDL03-24D05W |
9 ~ 36 VDC |
±5 VDC / ±0.3 A |
| RDL03-24D12W |
9 ~ 36 VDC |
±12 VDC / ±0.125 A |
| RDL03-24D15W |
9 ~ 36 VDC |
±15 VDC / ±0.1 A |
| RDL03-48S3P3W |
18 ~ 75 VDC |
3.3 VDC / 0.7 A |
| RDL03-48S05W |
18 ~ 75 VDC |
5 VDC / 0.6 A |
| RDL03-48S09W |
18 ~ 75 VDC |
9 VDC / 0.333 A |
| RDL03-48S12W |
18 ~ 75 VDC |
12 VDC / 0.25 A |
| RDL03-48S15W |
18 ~ 75 VDC |
15 VDC / 0.2 A |
| RDL03-48S24W |
18 ~ 75 VDC |
24 VDC / 0.125 A |
| RDL03-48D05W |
18 ~ 75 VDC |
±5 VDC / ±0.3 A |
| RDL03-48D12W |
18 ~ 75 VDC |
±12 VDC / ±0.125 A |
| RDL03-48D15W |
18 ~ 75 VDC |
±15 VDC / ±0.1 A |
