300V输入电源模块CHB300-300S05N CHB300-300S48N
详细信息
| | 品牌：CINCON | | 加工定制：否 | | 输出电流：30 A | |
| | 输入电压：DC180-425V V | | 输出电压：5-48 V | | 输出功率：300 W | |
| | 负载范围：+/-2% | | 工作温度：-40--100 ℃ | | 型号：CHB300-300S24N CHB300-300S28N | |
CHB300-300S系列 300V输入电源模块 CHB300-300S05N CHB300-300S48N
CHB300-300S24N CHB300-300S28N
CHB300-300S12N
300W输出
效率90％
固定开关频率
输入欠压保护
过温保护
低空载功耗
过压/过流保护
远程开/关
半砖尺寸符合工业标准
离线系统使用PFC前端
Model List
| Part Number |
Input Voltage |
Output Voltage |
Output Current |
No load Input Current |
Efficiency (效率) |
I/O Isolation Voltage |
| CHB300-300S05 |
180~425V |
5V |
60A |
10mA |
89 |
3000VAC |
| CHB300-300S12 |
180~425V |
12V |
25A |
10mA |
88 |
3000VAC |
| CHB300-300S24 |
180~425V |
24V |
12.5A |
10mA |
90 |
3000VAC |
| CHB300-300S28 |
180~425V |
28V |
10.7A |
10mA |
90 |
3000VAC |
| CHB300-300S48 |
180~425V |
48V |
6.25A |
10mA |
90 |
3000VAC |
| CHB300-300S05N |
180~425V |
5V |
60A |
10mA |
89 |
3000VAC |
| CHB300-300S12N |
180~425V |
12V |
25A |
10mA |
88 |
3000VAC |
| CHB300-300S24N |
180~425V |
24V |
12.5A |
10mA |
90 |
3000VAC |
| CHB300-300S28N |
180~425V |
28V |
10.7A |
10mA |
90 |
3000VAC |
| CHB300-300S48N |
180~425V |
48V |
6.25A |
10mA |
90 |
3000VAC |
