直流电源模块HAE150-12S05 HAE150-24S28
详细信息
| | 品牌：P-DUKE | | 型号：HAE150-12S05 HAE150-12S12 HAE1 | | 加工定制：是 | |
| | 输出电流：30 A | | 输入电压：18-36V/36-72V V | | 输出电压：5-28 V | |
| | 输出功率：150 W | | 频率范围：50-80 | | 额定正向平均电流：15 | |
| | 工作温度：-40--85 ℃ | | 针脚数：8 | | | |
直流电源模块HAE150-12S05 HAE150-24S05 HAE150-24S12 HAE150-24S24 HAE150-24S28
特征
■无需小的低负荷
■2250VDC输入输出基本绝缘
| Model No |
Input Range |
Output Range |
| HAE150-12S3P3 |
9 ~ 22 VDC |
3.3 VDC / 40 A |
| HAE150-12S05 |
9 ~ 22 VDC |
5 VDC / 28 A |
| HAE150-12S12 |
8.5 ~ 22 VDC |
12 VDC / 12 A |
| HAE150-12S15 |
8.5 ~ 22 VDC |
15 VDC / 9.5 A |
| HAE150-12S24 |
8.5 ~ 22 VDC |
24 VDC / 6 A |
| HAE150-12S28 |
8.5 ~ 22 VDC |
28 VDC / 5 A |
| HAE150-12S48 |
8.5 ~ 22 VDC |
48 VDC / 3 A |
| HAE150-24S3P3 |
16.5 ~ 36 VDC |
3.3 VDC / 40 A |
| HAE150-24S05 |
16.5 ~ 36 VDC |
5 VDC / 30 A |
| HAE150-24S12 |
16.5 ~ 36 VDC |
12 VDC / 13 A |
| HAE150-24S15 |
16.5 ~ 36 VDC |
15 VDC / 10 A |
| HAE150-24S24 |
16.5 ~ 36 VDC |
24 VDC / 6.5 A |
| HAE150-24S28 |
16.5 ~ 36 VDC |
28 VDC / 5.5 A |
| HAE150-24S48 |
16.5 ~ 36 VDC |
48 VDC / 3.3 A |
扫一扫，手机浏览
￥2100.00
￥2450.00
￥345.00
￥375.00
￥590.00
￥345.00
