CHB100W系列PCB板安装电源转换器
详细信息
| | 品牌：CINCON | | 型号：CHB100W-24S05-CM CHB100W-24S12 | | 加工定制：是 | |
| | 输出电流：30 A | | 输入电压：12 V | | 输出电压：15 V | |
| | 输出功率：40 W | | 频率范围：50-80 | | 额定正向平均电流：69 | |
| | 工作温度：40 ℃ | | 针脚数：69 | | 产品认证：SOP | |
CHB100W系列PCB板安装电源转换器 CHB100W-24S3V3-CM CHB100W-24S05-CM CHB100W-24S28-CM CHB100W-24S24-CM
66到100 WATT 4：1 INPUT
DC-DC转换器
66-100W输出
半砖尺寸
五边盾金属外壳
调节输出
效率89％
连续短路保护
Model
Number |
Input |
Output |
Output Current |
Input Current |
效率 EFF |
| Min |
Max |
No Load |
Full Load |
| CHB100W-24S3V3-CM |
9-36V |
3.3V |
0mA |
20A |
35mA |
3333mA |
82.5 |
| CHB100W-24S05-CM |
9-36V |
5V |
0mA |
20A |
35mA |
4931mA |
84.5 |
| CHB100W-24S12-CM |
9-36V |
12V |
0mA |
8.3A |
35mA |
4854mA |
85.5 |
| CHB100W-24S15-CM |
9-36V |
15V |
0mA |
6.7A |
35mA |
4813mA |
87 |
| CHB100W-24S24-CM |
9-36V |
24V |
0mA |
4.17A |
35mA |
4766mA |
87.5 |
| CHB100W-24S28-CM |
9-36V |
28V |
0mA |
3.57A |
50mA |
4845mA |
86 |
| CHB100W-24S48-CM |
9-36V |
48V |
0mA |
2.08A |
35mA |
5042mA |
82.5 |
| CHB100W-48S3V3-CM |
18-75V |
3.3V |
0mA |
20A |
30mA |
1667mA |
82.5 |
| CHB100W-48S05-CM |
18-75V |
5V |
0mA |
20A |
30mA |
2422mA |
86 |
| CHB100W-48S12-CM |
18-75V |
12V |
0mA |
8.3A |
30mA |
2371mA |
87.5 |
| CHB100W-48S15-CM |
18-75V |
15V |
0mA |
6.7A |
30mA |
2379mA |
88 |
| CHB100W-48S24-CM |
18-75V |
24V |
0mA |
4.17A |
30mA |
2343mA |
89 |
| CHB100W-48S28-CM |
18-75V |
28V |
0mA |
3.57A |
50mA |
2422mA |
86 |
| CHB100W-48S48-CM |
18-75V |
48V |
0mA |
2.08A |
30mA |
2462mA |
84.5 |
