CINCON模块电源CQB50W12-72S24N CQB150W12-72S12N
详细信息
| | 品牌：CINCON | | 型号：CQB50W12-72S05N CQB50W12-72S48 | | 加工定制：是 | |
| | 输入电压：DC14-160V V | | 输出电压：5--48 V | | 输出功率：50 W | |
| | 工作温度：-40--100 ℃ | | | | | |
CINCON模块电源CQB50W12-72S24N CQB150W12-72S12N CQB50W12-72S05N CQB50W12-72S48N
30-50W DC-DC转换器
输入电压14-160VDC
30-50W绝缘输出
输入范围14-160VDC
铁路应用
远程开/关
效率89％
过温保护
过电压/电流保护
连续短路保护
低空载功耗
Model List
| Part Number |
Input Voltage |
Output Voltage |
Output Current |
No load Input Current |
Efficiency (效率) |
I/O Isolation Voltage |
| CQB50W12-72S05 |
14~160V |
5V |
6A |
5mA |
83 |
3000VDC |
| CQB50W12-72S12 |
14~160V |
12V |
4.2A |
5mA |
87 |
3000VDC |
| CQB50W12-72S24 |
14~160V |
24V |
2.1A |
5mA |
89 |
3000VDC |
| CQB50W12-72S48 |
14~160V |
48V |
1.05A |
8mA |
88 |
3000VDC |
| CQB50W12-72S05N |
14~160V |
5V |
6A |
5mA |
83 |
3000VDC |
| CQB50W12-72S12N |
14~160V |
12V |
4.2A |
5mA |
87 |
3000VDC |
| CQB50W12-72S24N |
14~160V |
24V |
2.1A |
5mA |
89 |
3000VDC |
| CQB50W12-72S48N |
14~160V |
48V |
1.05A |
8mA |
88 |
3000VDC |
