ARCH开关电源模块 ALC-12S5S ALC-12S
详细信息
| | 品牌：ARCH | | 型号：ALC-12S ALC-24S ALC-5S A | | 加工定制：是 | |
| | 输出电流：30 A | | 输入电压：12 V | | 输出电压：15 V | |
| | 输出功率：40 W | | 频率范围：50-90 | | 额定正向平均电流：63 | |
| | 工作温度：40 ℃ | | 针脚数：37 | | 产品认证：SOP | |
台湾ARCH开关电源模块 ALC-12S5S ALC-12S ALC-24S ALC-5S ALC-9S ALC-5S3.3S
紧凑尺寸为1.48 x 1.1 x 1.08英寸
包装：PCB可安装模块
工作温度：-40〜70度
90〜305 VAC通用输入范围
低纹波和噪音
空载功率<0.3W
单路，双路输出
规范
1.除非另有说明，否则规格均在标称输入电压，预热时间后+ 25°C。
2.用0.1U 50V // 47U 50V陶瓷盖测量。 交叉输出
| Input Specification |
|
| Characteristics |
Conditions |
|
| Voltage Range |
AC IN |
90 ~ 305 VAC
|
|
| DC IN |
120 ~ 430 VDC
|
|
| Frequency |
47 ~ 440 Hz |
|
| |
|
|
|
|
| Output Specification |
|
| Characteristics |
Conditions |
|
| Output Power |
8 Watt (max.) |
|
Voltage Accuracy
(Full Load and Nominal Vin) |
Single: |
|
|
| Dual: |
|
|
| |
|
|
| Minimum Load (at Full Load) |
Single |
|
Line Regulation
(S: LL TO Hat Full Load) |
Single: |
|
(typ.) |
|
| Dual: |
|
|
| |
|
|
Load Regulation
(S: LL TO HLat Full Load)
(D: LL TO HL at Full Load)
|
Single: |
|
(typ.) |
|
| Dual: |
|
|
| |
|
|
| Ripple (20MHz bandwidth) |
24S:<150mV (Vp-p) |
(max.) |
|
| others:<100mV (Vp-p) |
|
| Noise (20MHz bandwidth) |
24S:<200mV (Vp-p) |
(max.) |
|
| others:<150mV (Vp-p) |
|
| Temperature Coefficient |
±0.0002 / °C (max.) |
|
| Short Circuit Protection |
Hiccup mode, indefinite (automatic recovery) |
|
| |
|
|
|
|
| General Specification |
|
| Characteristics |
Conditions |
|
| Switching Frequency |
(typ.) |
|
| Isolation Voltage (Input to Output) |
3000 VAC (min.) |
|
| Operating Temperature |
-40°C to +70 °C (with derating) |
|
| Storage Temperature |
-40 °C to +85 °C |
|
| Humidity |
0.95 RH (max.) |
|
| Cooling |
Free-air convection |
|
| |
|
|
|
|
| Physical Specification |
|
| Characteristics |
Conditions |
|
| Dimension (Tolerance ±0.5) |
37.66 x 28.16 x 27.5 mm |
|
| 1.48 x 1.11 x 1.08 inches |
|
| Weight |
45 g |
|
| Case Material |
Plastic resin (flammability to UL 94V-0) |
|
| |
|
|
|
|
|
|
|
