CQB100-110S系列100W铁路电源CQB100-110S3V3
详细信息
| | 品牌：CINCON | | 型号：CQB100-110S12N CQB100-110S24N | | 加工定制：是 | |
| | 输出电流：30 A | | 输入电压：12 V | | 输出电压：25 V | |
| | 输出功率：40 W | | 频率范围：50-80 | | 额定正向平均电流：69 | |
| | 工作温度：40 ℃ | | 针脚数：36 | | 产品认证：SOP | |
CQB100-110S系列100W铁路电源CQB100-110S3V3N CQB100-110S12N CQB100-110S24N CQB100-110S05N
66-160VDC输入
DC-DC转换器
·100W输出
·1/4砖块大小
效率93％
·远程打开/关闭
·连续短路保护
·对于铁路应用程序
Model List
| Part Number |
Input Voltage |
Output Voltage |
Output Current |
No load Input Current |
Efficiency (效率) |
I/O Isolation Voltage |
| CQB100-110S3V3 |
66~160V |
3.3V |
25A |
40mA |
90 |
2250VDC |
| CQB100-110S05 |
66~160V |
5V |
20A |
30mA |
92.5 |
2250VDC |
| CQB100-110S12 |
66~160V |
12V |
8.4A |
40mA |
93 |
2250VDC |
| CQB100-110S24 |
66~160V |
24V |
4.2A |
60mA |
92 |
2250VDC |
| CQB100-110S3V3N |
66~160V |
3.3V |
25A |
40mA |
90 |
2250VDC |
| CQB100-110S05N |
66~160V |
5V |
20A |
30mA |
92.5 |
2250VDC |
| CQB100-110S12N |
66~160V |
12V |
8.4A |
40mA |
93 |
2250VDC |
| CQB100-110S24N |
66~160V |
24V |
4.2A |
60mA |
92 |
2250VDC |
