4000V绝缘电压电源模块AHCH05-5S AHCH05-3.3S
详细信息
| | 品牌：ARCH | | 型号： AHCH05-3.3S AHCH05 | | 加工定制：是 | |
| | 输出电流：30 A | | 输入电压：12 V | | 输出电压：25 V | |
| | 输出功率：40 W | | 频率范围：50-80 | | 额定正向平均电流：69 | |
| | 工作温度：40 ℃ | | 针脚数：36 | | 产品认证：SIP | |
4000V绝缘电压电源模块 AC90-305V输入 AHCH05-24S AHCH05-12S AHCH05-5S AHCH05-3.3S
紧凑尺寸，2.0 x 1.0 x 0.6英寸
封装：PCB可安装模块
工作温度：-40~70度
90~305 VAC通用输入范围
I / O绝缘电压4000VAC
低空载功耗<0.1W
规格
1.除非另有说明，否则规格在额定输入电压，+ 25°C预热。
2.用0.1U 50V // 47U 50V陶瓷盖测量。 交叉输出
| |
|
| Input Specification |
|
|
| |
Characteristics |
Conditions |
|
| |
Voltage Range |
AC IN |
90 ~ 305 VAC
|
|
| |
DC IN |
127 ~ 430 VDC
|
|
| |
Frequency |
47 ~ 440 Hz |
|
| |
|
|
|
|
|
| |
Output Specification |
|
| |
Characteristics |
Conditions |
|
| |
Output Power |
5 Watt (max.) |
|
| |
Voltage Accuracy
(Full Load and Nominal Vin) |
Single: |
±2% |
|
| |
|
|
|
| |
|
|
|
| |
Minimum Load (at Full Load) |
|
|
| |
Line Regulation
(LL TO HL at Full Load) |
Single: |
3.3S,5S:±0.2%
12S,24S:±0.1% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Load Regulation
(LL TO HLat Full Load)
|
Single: |
±0.5% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Ripple (20MHz bandwidth) |
3.3S,5S:<100mV (Vp-p) |
(max.) |
|
| |
12S:<150mV (Vp-p)
24S:<200mV (Vp-p) |
|
| |
Noise (20MHz bandwidth) |
3.3S,5S:<100mV (Vp-p) |
(max.) |
|
| |
12S:<150mV (Vp-p)
24S:<200mV (Vp-p) |
|
| |
Temperature Coefficient |
±0.02% / °C (max.) |
|
| |
Short Circuit Protection |
Hiccup mode, indefinite (automatic recovery) |
|
| |
|
|
|
|
|
| |
General Specification |
|
| |
Characteristics |
Conditions |
|
| |
Switching Frequency |
(typ.) |
|
| |
Isolation Voltage (Input to Output) |
4000 VAC (min.) |
|
| |
Operating Temperature |
-40 °C to +70 °C (with derating) |
|
| |
Storage Temperature |
-40 °C to +85 °C |
|
| |
Humidity |
95% RH (max.) |
|
| |
Cooling |
Free-air convection |
|
| |
|
|
|
|
|
| |
Physical Specification |
|
| |
Characteristics |
Conditions |
|
| |
Dimension (Tolerance ±0.5) |
51.82 x 26.42 x 16.5 mm |
|
| |
2.04 x 1.04 x 0.65 inches |
|
| |
Weight |
In Progress |
|
| |
Case Material |
Plastic resin with Fiberglass (flammability to UL 94V-0) |
|
| |
|
|
|
|
|
Model No.
(Ordering Part No.) |
Input Range |
Output Voltage |
Output Current |
Eff |
| ( V.AC ) |
( V.DC ) |
( mA ) |
( % ) |
| Single Output Models |
| AHCH05-3.3S |
90 ~ 305 VAC |
3.3 |
1515 |
72 |
| AHCH05-5S |
90 ~ 305 VAC |
|
1000 |
77 |
| AHCH05-12S |
90 ~ 305 VAC |
12 |
420 |
80 |
| AHCH05-24S |
90 ~ 305 VAC |
24 |
210 |
81 |
| |
| |
| |
|
|
|
| |
Please refer to the PDF file published on the web site as the final version. |
|
