TRACOPOWERPCB电源模块TEP100-4810WIR TEP100-4811WIR
详细信息
| | 品牌：TRACOPOWER | | 型号：TEP100-7215WIR TEP100-7216WIR | | 加工定制：是 | |
| | 输出电流：30 A | | 输入电压：12 V | | 输出电压：25 V | |
| | 输出功率：40 W | | 频率范围：50-80 | | 额定正向平均电流：69 | |
| | 工作温度：40 ℃ | | 针脚数：36 | | 产品认证：SIP | |
TRACOPOWER PCB电源模块TEP100-2411WIR TEP100-2415WIR TEP100-4811WIR TEP100-7212WIR TEP100-7215WIR
TEP 100 WIR系列是一组绝缘式DC-DC转换器模块，具有4：1输入电压范围，采用坚固密封的工业标准半砖封装。 使用可选的安装散热器在60°C冷却，或者安装在铁基板上时可以85°C。 典型应用包括数据通信，工业控制和车载配电铁路系统。这些系列可根据需要提供许多可选设计
特点
紧凑的金属包装
4：1输入电压范围9-36,18-75,43-160 VDC
效率92％
软启动
可调输出电压+ 10 / - 20％
意义线
欠压锁定电路
过温保护
Models
| Order code |
Input |
Output |
Product Distinction |
| TEP100-2410WIR |
9 - 36 VDC |
3.3 VDC / 25 A |
PCB mount (option on demand) |
| TEP100-2411WIR |
9 - 36 VDC |
5 VDC / 20 A |
PCB mount |
| TEP100-2412WIR |
8.5 - 36 VDC |
12 VDC / 8.4 A |
PCB mount |
| TEP100-2413WIR |
8.5 - 36 VDC |
15 VDC / 6.7 A |
PCB mount (option on demand) |
| TEP100-2415WIR |
8.5 - 36 VDC |
24 VDC / 4200 mA |
PCB mount |
| TEP100-2416WIR |
8.5 - 36 VDC |
28 VDC / 3600 mA |
PCB mount |
| TEP100-2418WIR |
8.5 - 36 VDC |
48 VDC / 2100 mA |
PCB mount |
| TEP100-4810WIR |
16.5 - 75 VDC |
3.3 VDC / 25 A |
PCB mount (option on demand) |
| TEP100-4811WIR |
16.5 - 75 VDC |
5 VDC / 20 A |
PCB mount (option on demand) |
| TEP100-4812WIR |
16.5 - 75 VDC |
12 VDC / 8.4 A |
PCB mount |
| TEP100-4813WIR |
16.5 - 75 VDC |
15 VDC / 6.7 A |
PCB mount (on demand) |
| TEP100-4815WIR |
16.5 - 75 VDC |
24 VDC / 4200 mA |
PCB mount |
| TEP100-4816WIR |
16.5 - 75 VDC |
28 VDC / 3600 mA |
PCB mount |
| TEP100-4818WIR |
16.5 - 75 VDC |
48 VDC / 2100 mA |
PCB mount |
| TEP100-7210WIR |
43 - 160 VDC |
3.3 VDC / 25 A |
PCB mount (option on demand) |
| TEP100-7211WIR |
43 - 160 VDC |
5 VDC / 20 A |
PCB mount (option on demand) |
| TEP100-7212WIR |
43 - 160 VDC |
12 VDC / 8.4 A |
PCB mount |
| TEP100-7213WIR |
43 - 160 VDC |
15 VDC / 6.7 A |
PCB mount (option on demand) |
| TEP100-7215WIR |
43 - 160 VDC |
24 VDC / 4200 mA |
PCB mount |
| TEP100-7216WIR |
43 - 160 VDC |
28 VDC / 3600 mA |
PCB mount |
| TEP100-7218WIR |
43 - 160 VDC |
48 VDC / 2100 mA |
PCB mount |
| TEP100-2410WIRCM |
9 - 36 VDC |
3.3 VDC / 25 A |
Chassis mount (option on demand) |
| TEP100-2411WIRCM |
9 - 36 VDC |
5 VDC / 20 A |
Chassis mount (option on demand) |
| TEP100-2412WIRCM |
8.5 - 36 VDC |
12 VDC / 8.4 A |
Chassis mount (option on demand) |
| TEP100-2413WIRCM |
8.5 - 36 VDC |
15 VDC / 6.7 A |
Chassis mount (option on demand) |
| TEP100-2415WIRCM |
8.5 - 36 VDC |
24 VDC / 4200 mA |
Chassis mount (option on demand) |
| TEP100-2416WIRCM |
8.5 - 36 VDC |
28 VDC / 3600 mA |
Chassis mount (option on demand) |
