ARCH AC/DC开关电源 AQF700C-24S AQF700C-28S AQF700C-48S
详细信息
| 品牌: ARCH | | 类型:AC/DC电源 | | 输入电压:AC85-264 V | |
| 输出功率:700 W | | 调制方式:脉冲宽度调制(PWM)式 | | 晶体管连接方式:单端式 | |
| 输出电压:5V--48V V | | 工作效率:87 % | | 型号:AQF700C-48S AQF700C-12S | |
700W ARCH AC/DC
电源供应器 AQF700C-24S AQF700C-28S AQF700C-48S AQF700C-12S AQF700C-15S
绿色电源(低待机)700
瓦功能
AQF700
系列
紧凑尺寸,6.7 x 3.66 x 1.61
英寸
包装:附上
工作温度:-30~70
度
90~264 VAC
通用输入范围
远程开/
关功能
待机5V @ 1A
效率92
%
与P.F.C.
功能> 0.9
规范
1.
除非另有说明,否则规格在额定输入电压,+ 25
°C
预热后均。
2.
用0.1U 50V // 47U 50V
陶瓷盖测量。交叉输出
Specification |
|
1.All specifications valid at nominal input voltage,full load and +25°C after warm-up time unless otherwise stated.
2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output |
|
|
|
|
|
|
|
|
Input Specification |
|
|
Characteristics |
Conditions |
|
|
Voltage Range |
AC IN |
90 ~ 264 VAC
|
|
|
DC IN |
|
|
|
Frequency |
47 ~ 63 Hz |
|
|
|
|
|
|
|
|
|
|
|
General Specification |
|
|
Characteristics |
Conditions |
|
|
Switching Frequency |
(typ.) |
|
|
Isolation Voltage (Input to Output) |
4000VAC or 5656VDC (min.) |
|
|
Operating Temperature |
-30 °C to +70 °C (with derating) |
|
|
Storage Temperature |
-35 °C to +85 °C |
|
|
Humidity |
95% RH (max.) |
|
|
Cooling |
|
|
|
|
|
|
|
|
|
Physical Specification |
|
|
Characteristics |
Conditions |
|
|
Dimension (Tolerance ±0.5) |
170.2 x 93.0 x 41.0 mm |
|
|
6.7 x 3.66 x 1.61 inches |
|
|
Weight |
In Progress |
|
|
Case Material |
Enclosed |
|
Model |
|
|
|
|
|
|
|
|
Model No.
(Ordering Part No.) |
Input Range |
Output Voltage |
Output Current |
Eff |
( V.AC ) |
( V.DC ) |
( mA ) |
( 效率 ) |
Single Output Models |
AQF700C-12S |
90 ~ 264 VAC |
12 |
(at 115 VAC):50,000
(at 230 VAC):52,080 |
89 |
AQF700C-15S |
90 ~ 264 VAC |
15 |
(at 115 VAC):40,000
(at 230 VAC):41,660 |
90 |
AQF700C-24S |
90 ~ 264 VAC |
24 |
(at 115 VAC):28,130
(at 230 VAC):29,160 |
91 |
AQF700C-28S |
90 ~ 264 VAC |
28 |
(at 115 VAC):24,100
(at 230 VAC):25,000 |
92 |
AQF700C-48S |
90 ~ 264 VAC |
48 |
(at 115 VAC):14,060
(at 230 VAC):14,580 |
92 |
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
