CINCON开放式开关电源CFM130S240-C CFM130S120-CCFM130S480-C CFM130S360-C
详细信息
| | 品牌：CINCON | | 类型：AC/DC电源 | | 输入电压：80〜264VAC V | |
| | 输出功率：130 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC12V-48V V | | 工作效率：92 % | | 输出电压精度：+/-2 % | |
| | 电压调整率：+/-2 % | | 负载调整率：+/-2 % | | 输出电流：11 A | |
| | 型号：CFM130S480-C CFM130S360-C | | | | | |
CINCON开放式开关电源CFM130S240-C CFM130S120-C CFM130S480-C CFM130S360-C
130W AC-DC 2
” x3
” ITE
开放式底板冷却电源
CFM130S
通用输入范围80
〜264VAC
效率94
％
2
“ x 3
”开放式紧凑型
100W
自然对流
130W
带风扇冷却
主动PFC
功能
连续短路保护
空载输入功耗<150Mw
工作海拔5000m
Model List
| Part Number |
Power (Watts) |
Input Voltage |
Output Voltage |
Output Current |
Efficiency (效率) |
Operating Altitude |
Operating Temperature |
| CFM130S120 |
129.6W |
80-264 |
12V |
10.8A |
93% |
5000m |
-30°C ~70°C |
| CFM130S240 |
129.6W |
80-264 |
24V |
5.4A |
93% |
5000m |
-30°C ~70°C |
| CFM130S360 |
129.6W |
80-264 |
36V |
3.6A |
94% |
5000m |
-30°C ~70°C |
| CFM130S480 |
129.6W |
80-264 |
48V |
2.7A |
94% |
5000m |
-30°C ~70°C |
| CFM130S120-B |
129.6W |
80-264 |
12V |
10.8A |
93% |
5000m |
-30°C ~70°C |
| CFM130S240-B |
129.6W |
80-264 |
24V |
5.4A |
93% |
5000m |
-30°C ~70°C |
| CFM130S360-B |
129.6W |
80-264 |
36V |
3.6A |
94% |
5000m |
-30°C ~70°C |
| CFM130S480-B |
129.6W |
80-264 |
48V |
2.7A |
94% |
5000m |
-30°C ~70°C |
| CFM130S120-C |
129.6W |
80-264 |
12V |
10.8A |
93% |
5000m |
-30°C ~70°C |
| CFM130S240-C |
129.6W |
80-264 |
24V |
5.4A |
93% |
5000m |
-30°C ~70°C |
| CFM130S360-C |
129.6W |
80-264 |
36V |
3.6A |
94% |
5000m |
-30°C ~70°C |
| CFM130S480-C |
129.6W |
80-264 |
48V |
2.7A |
94% |
5000m |
-30°C ~70°C |
