• CINCONCFM40S系列开关电源CFM40S480-CA CFM40S360-CACFM40S240-CA CFM40S120-CA

    详细信息

     品牌:CINCON  类型:AC/DC电源  输入电压:AC85-264 V
     输出功率:40W W 调制方式:脉冲宽度调制(PWM)式  晶体管连接方式:单端式
     输出电压:5V--48V V 工作效率:87 % 输出波纹噪音:60mv
     输出电压精度:+/-2 % 电压调整率:+/-2 % 负载调整率:+/-2 %
     输出电流:0-8 A 型号:CFM40S240-CA CFM40S120-CA
    CFM40S系列40W CINCON AC/DC基板式开关电源CFM40S480-CA CFM40S360-CA CFM40S300-CA CFM40S240-CA CFM40S120-CA
    40瓦特开放框架
    通用输入90 - 264VAC
    2x 4”大小

    短路保护
    过电压保护
    效率87

    Model List
    Part Number Power (Watts) Input Voltage Output Voltage Output Current Efficiency (效率) Operating Altitude Operating Temperature
    CFM40S033 19.8W 90-264 3.3V 6A 70% 2000m 0°C ~ 70°C
    CFM40S050 30W 90-264 5V 6A 76% 2000m 0°C ~ 70°C
    CFM40S090 40.05W 90-264 9V 4.45A 84% 2000m 0°C ~ 70°C
    CFM40S120 40.08W 90-264 12V 3.34A 85% 2000m 0°C ~ 70°C
    CFM40S150 40.05W 90-264 15V 2.67A 85% 2000m 0°C ~ 70°C
    CFM40S240 40.08W 90-264 24V 1.67A 85% 2000m 0°C ~ 70°C
    CFM40S300 39.9W 90-264 30V 1.33A 86% 2000m 0°C ~ 70°C
    CFM40S360 39.96W 90-264 36V 1.11A 87% 2000m 0°C ~ 70°C
    CFM40S480 40.032W 90-264 48V 0.834A 87% 2000m 0°C ~ 70°C
    CFM40S033-CA 19.8W 90-264 3.3V 6A 70% 2000m 0°C ~ 70°C
    CFM40S050-CA 30W 90-264 5V 6A 76% 2000m 0°C ~ 70°C
    CFM40S090-CA 40.05W 90-264 9V 4.45A 84% 2000m 0°C ~ 70°C
    CFM40S120-CA 40.08W 90-264 12V 3.34A 85% 2000m 0°C ~ 70°C
    CFM40S150-CA 40.05W 90-264 15V 2.67A 85% 2000m 0°C ~ 70°C
    CFM40S240-CA 40.08W 90-264 24V 1.67A 85% 2000m 0°C ~ 70°C
    CFM40S300-CA 39.9W 90-264 30V 1.33A 86% 2000m 0°C ~ 70°C
    CFM40S360-CA 39.96W 90-264 36V 1.11A 87% 2000m 0°C ~ 70°C
    CFM40S480-CA 40.032W 90-264 48V 0.834A 87% 2000m 0°C ~ 70°C
    CFM40S033-P 19.8W 90-264 3.3V 6A 70% 2000m 0°C ~ 70°C
    CFM40S050-P 30W 90-264 5V 6A 76% 2000m 0°C ~ 70°C
    CFM40S090-P 40.05W 90-264 9V 4.45A 84% 2000m 0°C ~ 70°C
    CFM40S120-P 40.08W 90-264 12V 3.34A 85% 2000m 0°C ~ 70°C
    CFM40S150-P 40.05W 90-264 15V 2.67A 85% 2000m 0°C ~ 70°C
    CFM40S240-P 40.08W 90-264 24V 1.67A 85% 2000m 0°C ~ 70°C
    CFM40S300-P 39.9W 90-264 30V 1.33A 86% 2000m 0°C ~ 70°C
    CFM40S360-P 39.96W 90-264 36V 1.11A 87% 2000m 0°C ~ 70°C
    CFM40S480-P 40.032W 90-264 48V 0.834A 87% 2000m 0°C ~ 70°C
