P-DUKE1600VDC绝缘电压模块电源LDL03-05S12
详细信息
| | 品牌：P-DUKE | | 类型：模块电源 | | 输入电压：4.5 ~ 13.2 VDC V | |
| | 输出功率：3 W | | 调制方式：脉冲频率调制（PFM）式 | | 晶体管连接方式：推挽式 | |
| | 工作效率：85 % | | 输出电压精度：73 % | | 电压调整率：60 % | |
| | 负载调整率：64 % | | 输出电流：7 A | | 型号：LDL03-05S12 | |
1600VDC绝缘
电压模块电源LDL03-05D05 LDL03-05S05 LDL03-05S12 LDL03-05S15 LDL03-12S05 LDL03-12S15
产品特性
■3W
，SIP-8
，稳压DC-DC
转换器
■1600VDC绝缘
电压
■2
：1
输入范围
■低纹波和噪声（5mVp-p
）
■工作温度：-40
℃〜＋ 105
℃
| 產品型號 |
輸入範圍 |
輸出電壓 |
| LDL03-05S3P3 |
4.5 ~ 13.2 VDC |
3.3 VDC / 700 mA |
| LDL03-05S05 |
4.5 ~ 13.2 VDC |
5 VDC / 600 mA |
| LDL03-05S09 |
4.5 ~ 13.2 VDC |
9 VDC / 333 mA |
| LDL03-05S12 |
4.5 ~ 13.2 VDC |
12 VDC / 250 mA |
| LDL03-05S15 |
4.5 ~ 13.2 VDC |
15 VDC / 200 mA |
| LDL03-05S24 |
4.5 ~ 13.2 VDC |
24 VDC / 125 mA |
| LDL03-05D05 |
4.5 ~ 13.2 VDC |
±5 VDC / ±300 mA |
| LDL03-05D12 |
4.5 ~ 13.2 VDC |
±12 VDC / ±125 mA |
| LDL03-05D15 |
4.5 ~ 13.2 VDC |
±15 VDC / ±100 mA |
| LDL03-12S3P3 |
9 ~ 18 VDC |
3.3 VDC / 700 mA |
| LDL03-12S05 |
9 ~ 18 VDC |
5 VDC / 600 mA |
| LDL03-12S09 |
9 ~ 18 VDC |
9 VDC / 333 mA |
| LDL03-12S12 |
9 ~ 18 VDC |
12 VDC / 250 mA |
| LDL03-12S15 |
9 ~ 18 VDC |
15 VDC / 200 mA |
| LDL03-12S24 |
9 ~ 18 VDC |
24 VDC / 125 mA |
| LDL03-12D05 |
9 ~ 18 VDC |
±5 VDC / ±300 mA |
| LDL03-12D12 |
9 ~ 18 VDC |
±12 VDC / ±125 mA |
| LDL03-12D15 |
9 ~ 18 VDC |
±15 VDC / ±100 mA |
| LDL03-24S3P3 |
18 ~ 36 VDC |
3.3 VDC / 700 mA |
| LDL03-24S05 |
18 ~ 36 VDC |
5 VDC / 600 mA |
| LDL03-24S09 |
18 ~ 36 VDC |
9 VDC / 333 mA |
| LDL03-24S12 |
18 ~ 36 VDC |
12 VDC / 250 mA |
| LDL03-24S15 |
18 ~ 36 VDC |
15 VDC / 200 mA |
| LDL03-24S24 |
18 ~ 36 VDC |
24 VDC / 125 mA |
| LDL03-24D05 |
18 ~ 36 VDC |
±5 VDC / ±300 mA |
| LDL03-24D12 |
18 ~ 36 VDC |
±12 VDC / ±125 mA |
| LDL03-24D15 |
18 ~ 36 VDC |
±15 VDC / ±100 mA |
| LDL03-48S3P3 |
36 ~ 75 VDC |
3.3 VDC / 700 mA |
| LDL03-48S05 |
36 ~ 75 VDC |
5 VDC / 600 mA |
| LDL03-48S09 |
36 ~ 75 VDC |
9 VDC / 333 mA |
| LDL03-48S12 |
36 ~ 75 VDC |
12 VDC / 250 mA |
| LDL03-48S15 |
36 ~ 75 VDC |
15 VDC / 200 mA |
| LDL03-48S24 |
36 ~ 75 VDC |
24 VDC / 125 mA |
| LDL03-48D05 |
36 ~ 75 VDC |
±5 VDC / ±300 mA |
| LDL03-48D12 |
36 ~ 75 VDC |
±12 VDC / ±125 mA |
| LDL03-48D15 |
36 ~ 75 VDC |
±15 VDC / ±100 mA |
