详细信息

品牌：幸康	型号：EC1SA04N EC1SA05N EC1SA06N	加工定制：否
输出电流：0-6 A	输入电压：DC4.5-26.4V V	输出电压：DC3.3-15 V
输出功率：1 W	额定正向平均电流：6	工作温度：-40--85 ℃

幸康DC-DC转换器EC1SA01N EC1SA02N EC1SA03N EC1SA04N EC1SA05N EC1SA06N
1W SIP-7非稳压DC-DC转换器
EC1SAN
SIP-7和SMD封装

效率83％

绝缘1500VDC

低纹波和噪音

里面没有钽电容器

Model List

Part Number	Input Voltage	Output Voltage	Output Current	No load Input Current	Efficiency (效率)	I/O Isolation Voltage
EC1SA11N	10.8~13.2V	5V	0.2A	15mA	80	1500VDC
EC1SA12N	10.8~13.2V	12V	0.084A	15mA	81	1500VDC
EC1SA13N	10.8~13.2V	15V	0.067A	15mA	81	1500VDC
EC1SA14N	10.8~13.2V	±12V	±0.042A	15mA	80	1500VDC
EC1SA15N	10.8~13.2V	±15V	±0.033A	15mA	81	1500VDC
EC1SA16N	10.8~13.2V	±5V	±0.1A	15mA	77	1500VDC
EC1SA11NS	10.8~13.2V	5V	0.2A	15mA	80	1500VDC
EC1SA12NS	10.8~13.2V	12V	0.084A	15mA	81	1500VDC
EC1SA13NS	10.8~13.2V	15V	0.067A	15mA	81	1500VDC
EC1SA14NS	10.8~13.2V	±12V	±0.042A	15mA	80	1500VDC
EC1SA15NS	10.8~13.2V	±15V	±0.033A	15mA	81	1500VDC
EC1SA16NS	10.8~13.2V	±5V	±0.1A	15mA	77	1500VDC
EC1SA21N	21.6~26.4V	5V	0.2A	7mA	80	1500VDC
EC1SA22N	21.6~26.4V	12V	0.084A	7mA	83	1500VDC
EC1SA23N	21.6~26.4V	15V	0.067A	7mA	81	1500VDC
EC1SA24N	21.6~26.4V	±12V	±0.042A	7mA	81	1500VDC
EC1SA25N	21.6~26.4V	±15V	±0.033A	7mA	82	1500VDC
EC1SA26N	21.6~26.4V	±5V	±0.1A	7mA	79	1500VDC
EC1SA01N	4.5~5.5V	5V	0.2A	40mA	79	1500VDC
EC1SA02N	4.5~5.5V	12V	0.084A	40mA	79	1500VDC
EC1SA03N	4.5~5.5V	15V	0.067A	40mA	79	1500VDC
EC1SA04N	4.5~5.5V	±12V	±0.042A	40mA	78	1500VDC
EC1SA05N	4.5~5.5V	±15V	±0.033A	40mA	78	1500VDC
EC1SA06N	4.5~5.5V	±5V	±0.1A	40mA	74	1500VDC
EC1SA01NS	4.5~5.5V	5V	0.2A	40mA	79	1500VDC
EC1SA02NS	4.5~5.5V	12V	0.084A	40mA	79	1500VDC
EC1SA03NS	4.5~5.5V	15V	0.067A	40mA	79	1500VDC
EC1SA04NS	4.5~5.5V	±12V	±0.042A	40mA	78	1500VDC
EC1SA05NS	4.5~5.5V	±15V	±0.033A	40mA	78	1500VDC
EC1SA06NS	4.5~5.5V	±5V	±0.1A	40mA	74	1500VDC
