TRACODC/DC电源模块TDN5-2422WISM TDN5-2411WISM TDN5-2412WISM TDN5-2415WISM TDN5-2423WISM
详细信息
| 品牌:TRACO | | 型号:TDN5-2415WISM TDN5-2423WISM | | 加工定制:否 | |
| 输出电流:1 A | | 输入电压:DC9-36 V | | 输出电压:DC3.3-24 V | |
| 输出功率:5 W | | 工作温度:-40--85 ℃ | | | |
DC/DC
电源模块TDN5-2422WISM TDN5-2411WISM TDN5-2412WISM TDN5-2415WISM TDN5-2423WISM
TDN5WISM
系列重新定义了DC / DC
转换器的功率密度。 仅1.23 cm3
的立方封装封装了一个复杂的电路,该电路可提供5
瓦的输出功率,而不会影响可靠性和功能性。 它们在满载条件下可在50
°C
的环境温度下运行,在额定负载降低50
%时可在70
°C
的环境下运行。 凭借1500 VDC I / O
隔离电压,外部开/
关和短路电流保护功能,它们在空间有限的情况下可以应用。 转换器的输入设计用于宽电压范围(4
:1
),并且不需要小负载。
特征
紧凑的SMD
封装13,2 x 9,1 x 10,2 mm
规范的输出
I / O
绝缘1
′500 VDC
工作温度范围-40
°C
至+ 75
°C
短路保护
远程开/
关
3
年产品保修
Models
Order code |
Input |
Output |
TDN5-0910WISM |
4.5 - 13.2 VDC |
3.3 VDC / 1000 mA |
TDN5-0911WISM |
4.5 - 13.2 VDC |
5 VDC / 1000 mA |
TDN5-0919WISM |
4.5 - 13.2 VDC |
9 VDC / 555 mA |
TDN5-0912WISM |
4.5 - 13.2 VDC |
12 VDC / 420 mA |
TDN5-0913WISM |
4.5 - 13.2 VDC |
15 VDC / 333 mA |
TDN5-0915WISM |
4.5 - 13.2 VDC |
24 VDC / 210 mA |
TDN5-0921WISM |
4.5 - 13.2 VDC |
5 VDC / 500 mA | -5 VDC / -500 mA |
TDN5-0922WISM |
4.5 - 13.2 VDC |
12 VDC / 210 mA | -12 VDC / -210 mA |
TDN5-0923WISM |
4.5 - 13.2 VDC |
15 VDC / 168 mA | -15 VDC / -168 mA |
TDN5-2410WISM |
9 - 36 VDC |
3.3 VDC / 1000 mA |
TDN5-2411WISM |
9 - 36 VDC |
5 VDC / 1000 mA |
TDN5-2419WISM |
9 - 36 VDC |
9 VDC / 555 mA |
TDN5-2412WISM |
9 - 36 VDC |
12 VDC / 420 mA |
TDN5-2413WISM |
9 - 36 VDC |
15 VDC / 333 mA |
TDN5-2415WISM |
9 - 36 VDC |
24 VDC / 210 mA |
TDN5-2421WISM |
9 - 36 VDC |
5 VDC / 500 mA | -5 VDC / -500 mA |
TDN5-2422WISM |
9 - 36 VDC |
12 VDC / 210 mA | -12 VDC / -210 mA |
TDN5-2423WISM |
9 - 36 VDC |
15 VDC / 168 mA | -15 VDC / -168 mA |
TDN5-4810WISM |
18 - 75 VDC |
3.3 VDC / 1000 mA |
TDN5-4811WISM |
18 - 75 VDC |
5 VDC / 1000 mA |
TDN5-4819WISM |
18 - 75 VDC |
9 VDC / 555 mA |
TDN5-4812WISM |
18 - 75 VDC |
12 VDC / 420 mA |
TDN5-4813WISM |
18 - 75 VDC |
15 VDC / 333 mA |
TDN5-4815WISM |
18 - 75 VDC |
24 VDC / 210 mA |
TDN5-4821WISM |
18 - 75 VDC |
5 VDC / 500 mA | -5 VDC / -500 mA |
TDN5-4822WISM |
18 - 75 VDC |
12 VDC / 210 mA | -12 VDC / -210 mA |
TDN5-4823WISM |
18 - 75 VDC |
15 VDC / 168 mA | -15 VDC / -168 mA |
