| Feature |
|
|
| |
Compact Size in 2.06 x 1.07 x 0.93 inches
Package: Module, Screw Terminal
Operating Temperature: -40~70 degrees
90~264 VAC Universal Input Range
Isolation Class II
Regulated Output
Low Ripple and Noise
Low Standby <0.5W
Small Size as AFC 10Watt with 20Watt Higher Power
Screw Terminal For Optional
Safety approval by CE and UL |
|
| |
| Specification |
| |
1.All specificationsvalid at nominal input voltage,full load and +25°Cafter warm-up time
unless otherwise stated.
2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output |
| |
Input Specification |
|
| |
Characteristics |
Conditions |
|
| |
Voltage Range |
AC IN |
90 ~ 264 VAC |
|
| |
DC IN |
120 ~ 370 VDC |
|
| |
Frequency |
47 ~ 440 Hz |
|
| |
|
|
|
|
|
| |
Output Specification |
|
| |
Characteristics |
Conditions |
|
| |
Output Power |
20 Watt (max.) |
|
| |
Voltage Accuracy
(Full Load and Nominal Vin) |
Single: |
±2% |
|
| |
|
|
|
| |
|
|
|
| |
Minimum Load (at Full Load) |
0% |
|
| |
Line Regulation
(LL to HL at Full Load) |
Single: |
±0.5% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Load Regulation
(LL to HL at Full Load)
|
Single: |
±1% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Ripple (20MHz bandwidth) |
3.3S,5S:75mV (Vp-p) |
(max.) |
|
| |
others:1% Vout |
|
| |
Noise (20MHz bandwidth) |
3.3S,5S:120mV (Vp-p) |
(max.) |
|
| |
others:1% Vout |
|
| |
Temperature Coefficient |
±0.02% / °C (max.) |
|
| |
Short Circuit Protection |
Hiccup mode, indefinite (automatic recovery) |
|
| |
|
|
|
|
|
| |
General Specification |
|
| |
Characteristics |
Conditions |
|
| |
Switching Frequency |
100K ~ 133K Hz (typ.) |
|
| |
Isolation Voltage (Input to Output) |
3000 VAC (min.) |
|
| |
Operating Temperature |
-40 °C to +70°C (with derating) |
|
| |
Storage Temperature |
-40°C to +85°C |
|
| |
Humidity |
95% RH (max.) |
|
| |
Cooling |
Free air convection |
|
| |
|
|
|
|
|
| |
Physical Specification |
|
| |
Characteristics |
Conditions |
|
| |
Dimension (Tolerance ±0.5) |
52.4 x 27.2 x 23.5 mm |
|
| |
2.06 x 1.07 x 0.93 inches |
|
| |
Weight |
59 g |
|
| |
Case Material |
Plastic resin with Fiberglass (flammability to UL 94V-0) |
|
| |
|
|
|
|
|
