ARCHAKC系列20W AC/DC小尺寸电源
详细信息
| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC85-264 V | |
| | 输出功率：20 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC5-24 V | | 工作效率：85 % | | 型号：AKC-5D,AKC-15D,AKC-12D,AKC-24S | |
| |
| |
| AC-DC Power Module |
| |
AKC Series |
|
| |
[ 20 Watts ] |
| |
|
|
| |
| |
| Feature |
|
|
| |
Compact Size in 2.76 x 1.89 x 0.87 inches
Package: Module, Screw Terminal
Operating Temperature: -25~70 degrees
90~264 VAC Universal Input Range
Isolation Class II
Regulated Output
Low Ripple and Noise
Small Size But Higher Wattage
Screw Terminal For Optional
Safety approval by CE and UL |
|
| |
| Specification |
| |
1.All specificationsvalid at nominal input voltage,full load and +25°Cafter warm-up time
unless otherwise stated.
2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output |
| |
Input Specification |
|
| |
Characteristics |
Conditions |
|
| |
Voltage Range |
AC IN |
90 ~ 264 VAC |
|
| |
DC IN |
100 ~ 375 VDC |
|
| |
Frequency |
47 ~ 440 Hz |
|
| |
|
|
|
|
|
| |
Output Specification |
|
| |
Characteristics |
Conditions |
|
| |
Output Power |
20 Watt (max.) |
|
| |
Voltage Accuracy
(Full Load and Nominal Vin) |
Single: |
±2% |
|
| |
Dual: |
±2% |
|
| |
Triple: |
±2% |
|
| |
Minimum Load (at Full Load) |
0% to 10% |
|
| |
Line Regulation
(LL to HL at Full Load) |
Single: |
±0.5% |
(typ.) |
|
| |
Dual: |
±0.5% |
|
| |
Triple: |
±1% / ±5% |
|
| |
Load Regulation
(S: LL to HLat Full Load)
(D: LL to HL at Full Load)
(T: LL to HLat Full Load) |
Single: |
±1% |
(typ.) |
|
| |
Dual: |
±3% |
|
| |
Triple: |
±2% / ±5% |
|
| |
Ripple (20MHz bandwidth) |
<0.2% Vout +40mV |
(max.) |
|
| |
|
|
| |
Noise (20MHz bandwidth) |
<0.5% Vout +40mV |
(max.) |
|
| |
|
|
| |
Temperature Coefficient |
±0.02% / °C (max.) |
|
| |
Short Circuit Protection |
Hiccup mode, indefinite (automatic recovery) |
|
| |
|
|
|
|
|
| |
General Specification |
|
| |
Characteristics |
Conditions |
|
| |
Switching Frequency |
100K Hz (typ.) |
|
| |
Isolation Voltage (Input to Output) |
3000 VAC (min.) |
|
| |
Operating Temperature |
-25 °C to +70°C (with derating) |
|
| |
Storage Temperature |
-40°C to +85°C |
|
| |
Humidity |
95% RH (max.) |
|
| |
Cooling |
Free air convection |
|
| |
|
|
|
|
|
| |
Physical Specification |
|
| |
Characteristics |
Conditions |
|
| |
Dimension (Tolerance ±0.5) |
70.0 x 48.0 x 22.0 mm |
|
| |
2.76 x 1.89 x 0.87 inches |
|
| |
Weight |
110 g |
|
| |
Case Material |
Plastic resin with Fiberglass (flammability to UL 94V-0) |
|
| |
|
|
|
|
|
|
|
| |
Model |
|
| |
|
|
| |
|
|
| |
| ModelNo. |
InputRange |
OutputVoltage |
OutputCurrent |
Eff |
| (V.AC ) |
(V.DC ) |
(mA ) |
(%) |
| Single Output Models |
| AKC-3.3S |
90 ~ 264 VAC |
3.3 |
4500 |
75 |
| AKC-5S |
90 ~ 264 VAC |
5 |
4000 |
79 |
| AKC-7.35S |
90 ~ 264 VAC |
7.35 |
2730 |
82 |
| AKC-9S |
90 ~ 264 VAC |
9 |
2230 |
82 |
| AKC-12S |
90 ~ 264 VAC |
12 |
1670 |
83 |
| AKC-15S |
90 ~ 264 VAC |
15 |
1340 |
83 |
| AKC-24S |
90 ~ 264 VAC |
24 |
840 |
84 |
| |
| Dual Output Models |
| AKC-5D |
90 ~ 264 VAC |
±5 |
±2000 |
79 |
| AKC-12D |
90 ~ 264 VAC |
±12 |
±833 |
82 |
| AKC-15D |
90 ~ 264 VAC |
±15 |
±667 |
82 |
| |
| Triple Output Models |
| AKC-5S12D |
90 ~ 264 VAC |
5 / ±12 |
2800 / ±250 |
81 |
| AKC-5S15D |
90 ~ 264 VAC |
5 / ±15 |
2800 / ±200 |
81 |
|
|
|
|
|
