ARCHAPC系列开关电源模块APC-12S,APC-15D

ARCHAPC系列开关电源模块APC-12S,APC-15D

详细信息

品牌：ARCH	类型：AC/DC电源	输入电压：AC85-264 V
输出功率：5 W	调制方式：脉冲宽度调制（PWM)式	晶体管连接方式：单端式
输出电压：DC3.3-24 V	工作效率：86 %	型号：APC-5D,APC-24S

AC-DC Power Module
	APC Series
	[ 5 Watts ]

Feature

Safety Approval：

Compact Size in 2.17 x 1.77 x 0.81 inches
Package: Module, Din Rail, Screw Terminal
Operating Temperature: -25~70 degrees
90~264 VAC Universal Input Range
Isolation Class II
Regulated Output
Low Ripple and Noise
Screw Terminal For Optional

Specification

1.All specificationsvalid at nominal input voltage,full load and +25°Cafter warm-up time
unless otherwise stated.
2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output

Input Specification

Characteristics

Conditions

Voltage Range

AC IN

90 ~ 264 VAC

DC IN

120 ~ 370 VDC

Frequency

47 ~ 440 Hz

Output Specification

Characteristics

Conditions

Output Power

5 Watt (max.)

Voltage Accuracy
(Full Load and Nominal Vin)

Single:

±2%

Dual:

±2%

Minimum Load (at Full Load)

0% to 4%

Line Regulation
(LL to HL at Full Load)

Single:

±0.3%

(typ.)

Dual:

±0.3%

    Load Regulation
    (LL to HLat Full Load)

Single:

±0.5%

(typ.)

Dual:

±0.5%

Ripple (20MHz bandwidth)

<0.2% Vout+40mV

(max.)

Noise (20MHz bandwidth)

<0.5% Vout+50mV

(max.)

Temperature Coefficient

±0.02% / °C (max.)

Short Circuit Protection

Hiccup mode, indefinite (automatic recovery)

General Specification

Characteristics

Conditions

Switching Frequency

100K Hz (typ.)

Isolation Voltage (Input to Output)

3000 VAC (min.)

Operating Temperature

-25 °C to +70°C (with derating)

Storage Temperature

-40°C to +85°C

Humidity

95% RH (max.)

Cooling

Free-air convection

Physical Specification

Characteristics

Conditions

Dimension (Tolerance ±0.5)

55.0 x 45.0 x 20.5 mm

2.17 x 1.77 x 0.81 inches

Weight

80 g

Case Material

Plastic resin with Fiberglass (flammability to UL 94V-0)

Model

ModelNo.	InputRange	OutputVoltage	OutputCurrent	Eff
ModelNo.	(V.AC )	(V.DC )	(mA )	(%)
Single Output Models
APC-3.3S	90 ~ 264 VAC	3.3	1500	63
APC-5S	90 ~ 264 VAC	5	1000	71
APC-12S	90 ~ 264 VAC	12	416	75
APC-15S	90 ~ 264 VAC	15	333	75
APC-24S	90 ~ 264 VAC	24	200	74
APC-3.3S-A2	90 ~ 264 VAC	3.3	1500	63
APC-5S-A2	90 ~ 264 VAC	5	1000	71
APC-12S-A2	90 ~ 264 VAC	12	416	75
APC-15S-A2	90 ~ 264 VAC	15	333	75
APC-24S-A2	90 ~ 264 VAC	24	200	74
APC-3.3S-A4	90 ~ 264 VAC	3.3	1500	63
APC-5S-A4	90 ~ 264 VAC	5	1000	71
APC-12S-A4	90 ~ 264 VAC	12	416	75
APC-15S-A4	90 ~ 264 VAC	15	333	75
APC-24S-A4	90 ~ 264 VAC	24	200	74
APC-3.3S-A5	90 ~ 264 VAC	3.3	1500	63
APC-5S-A5	90 ~ 264 VAC	5	1000	71
APC-12S-A5	90 ~ 264 VAC	12	416	75
APC-15S-A5	90 ~ 264 VAC	15	333	75
APC-24S-A5	90 ~ 264 VAC	24	200	74
APC-3.3S-A7	90 ~ 264 VAC	3.3	1500	63
APC-5S-A7	90 ~ 264 VAC	5	1000	71
APC-12S-A7	90 ~ 264 VAC	12	416	75
APC-15S-A7	90 ~ 264 VAC	15	333	75
APC-24S-A7	90 ~ 264 VAC	24	200	74

Dual Output Models
APC-5D	90 ~ 264 VAC	±5	±500	72
APC-12D	90 ~ 264 VAC	±12	±200	74
APC-15D	90 ~ 264 VAC	±15	±160	74
APC-5D-A2	90 ~ 264 VAC	±5	±500	72
APC-12D-A2	90 ~ 264 VAC	±12	±200	74
APC-15D-A2	90 ~ 264 VAC	±15	±160	74
APC-5D-A4	90 ~ 264 VAC	±5	±500	72
APC-12D-A4	90 ~ 264 VAC	±12	±200	74
APC-15D-A4	90 ~ 264 VAC	±15	±160	74
APC-5D-A5	90 ~ 264 VAC	±5	±500	72
APC-12D-A5	90 ~ 264 VAC	±12	±200	74
APC-15D-A5	90 ~ 264 VAC	±15	±160	74
APC-5D-A7	90 ~ 264 VAC	±5	±500	72
APC-12D-A7	90 ~ 264 VAC	±12	±200	74
APC-15D-A7	90 ~ 264 VAC	±15	±160	74
