AQF100O系列开放式电源AQF100O-12S AQF100O-15S
详细信息
| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC85-264V V | |
| | 输出功率：100 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 型号：AQF100O-24S | | | | | |
| AC-DC Switching Power Supply |
| |
AQF100O Series |
|
| |
[ 65 W ~ 100 Watts ] |
| |
|
|
| |
| |
| Feature |
|
|
| |
Compact Size in 4.1 x 2.05 x 1.0 inches
Package: Open Frame
Operating Temperature: -25~70 degrees
90~264 VAC Universal Input Rang (80~274 VAC with Derating)
5 VDC to 48 VDC Output
Free Convection
High Efficiency up to 93%
With P.F.C. Function >0.95
Low Ripple and Noise
|
|
| |
| Specification |
| |
1.All specificationsvalid at nominal input voltage,full load and +25°Cafter warm-up time
unless otherwise stated.
2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output |
| |
Input Specification |
|
| |
Characteristics |
Conditions |
|
| |
Voltage Range |
AC IN |
90 ~ 264 VAC
( 80-274 VAC with Derating ) |
|
| |
DC IN |
120 ~ 370 VDC
( 110-390 VAC with Derating ) |
|
| |
Frequency |
47 ~ 63 Hz |
|
| |
|
|
|
|
|
| |
Output Specification |
|
| |
Characteristics |
Conditions |
|
| |
Output Power |
65 W ~ 100 Watt (max.) |
|
| |
Voltage Accuracy
(Full Load and Nominal Vin) |
Single: |
±2% |
|
| |
|
|
|
| |
|
|
|
| |
Minimum Load (at Full Load) |
|
|
| |
Line Regulation
(LL to HL at Full Load) |
Single: |
±1% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Load Regulation
|
Single: |
±1% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Ripple (20MHz bandwidth) |
5S:100mV
12S:120mV
15S:150mV |
(max.) |
|
| |
24S:200mV
48S:240mV |
|
| |
Noise (20MHz bandwidth) |
5S:100mV
12S:120mV
15S:150mV |
(max.) |
|
| |
24S:200mV
48S:240mV |
|
| |
Temperature Coefficient |
±0.03% / °C ( 0 °C~50 °C ) (max.) |
|
| |
Short Circuit Protection |
Auto recovery |
|
| |
|
|
|
|
|
| |
General Specification |
|
| |
Characteristics |
Conditions |
|
| |
Switching Frequency |
100K Hz (typ.) |
|
| |
Isolation Voltage (Input to Output) |
3000 VAC (min.) |
|
| |
Operating Temperature |
-25 °C to +70°C (with derating) |
|
| |
Storage Temperature |
-25°C to +85°C |
|
| |
Humidity |
95% RH (max.) |
|
| |
Cooling |
Free air convection |
|
| |
|
|
|
|
|
| |
Physical Specification |
|
| |
Characteristics |
Conditions |
|
| |
Dimension (Tolerance ±0.5) |
103.9 x 52.1 x 25.4 mm |
|
| |
4.1 x 2.05 x 1.0 inches |
|
| |
Weight |
200 g |
|
| |
Case Material |
Open Frame |
|
| |
|
|
|
|
|
|
|
| |
Model |
|
| |
|
|
| |
|
|
| |
| ModelNo. |
InputRange |
OutputVoltage |
OutputCurrent |
Eff |
| (V.AC ) |
(V.DC ) |
(mA ) |
(%) |
| Single Output Models |
| AQF100O-12S |
90 ~ 264 VAC |
12 ( 11.4 ~ 13.2 V ) |
0 ~ 8330 |
90 |
| AQF100O-15S |
90 ~ 264 VAC |
15 ( 13.5 ~ 16 V ) |
0 ~ 6660 |
90 |
| AQF100O-24S |
90 ~ 264 VAC |
24 ( 22.8 ~ 26.4 V ) |
0 ~ 4160 |
93 |
| AQF100O-48S |
90 ~ 264 VAC |
48 ( 45.6 ~ 52 V ) |
0 ~ 2090 |
93 |
| |
| |
| |
|
|
|
