AQF240E系列电源AQF240E-28S
详细信息
| | 品牌：510.00 | | 加工定制：否 | | 类型：铁磁谐振式交流稳压器 | |
| | 输入电压：AC85-264V V | | 输出电压：DC12-48V V | | 输出功率：240 W | |
| | 型号：AQF240E-12S,AQF240E-24S | | | | | |
| AQF240E Series ( AC-DC Switching Power Supply -----Enclosed ) |
|
| |
Green Power -----【High Efficiency 】 |
|
| |
|
Feature |
|
| |
|
|
| |
240 Watts |
| |
Compact Size in 6.0 x 4.18 x 1.38 inches |
| |
Package: Enclosed |
| |
Operating Temperature: -10~70 degrees |
| |
90~264 VAC Universal Input Range |
| |
12 VDC to 48 VDC Output |
| |
4000 VAC Input to Output Isolation |
| |
High Efficiency up to 93% |
| |
With P.F.C. Function, PF>0.95 |
| |
Free Air Convection |
| |
|
| |
|
|
|
| |
Safety Approval |
|
|
|
| |
|
|
|
|
| Specification |
| |
1.All specifications valid at nominal input voltage,full load and +25°C after warm-up time unless otherwise stated.
2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output |
|
| |
|
|
|
|
|
| |
Input Specification |
|
| |
Characteristics |
Conditions |
|
| |
Voltage Range |
AC IN |
90 ~ 264 VAC
|
|
| |
DC IN |
120 ~ 370 VDC
|
|
| |
Frequency |
47 ~ 63 Hz |
|
| |
|
|
|
|
|
| |
Output Specification |
|
| |
Characteristics |
Conditions |
|
| |
Output Power |
240 Watt (max.) |
|
| |
Voltage Accuracy
(Full Load and Nominal Vin) |
Single: |
±2% |
|
| |
|
|
|
| |
|
|
|
| |
Minimum Load (at Full Load) |
0% |
|
| |
Line Regulation
|
Single: |
±1% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Load Regulation
|
Single: |
±1% |
(typ.) |
|
| |
|
|
|
| |
|
|
|
| |
Ripple (20MHz bandwidth) |
12S:120mV (Vp-p) |
(max.) |
|
| |
others:200mV (Vp-p) |
|
| |
Noise (20MHz bandwidth) |
12S:120mV (Vp-p) |
(max.) |
|
| |
others:200mV (Vp-p) |
|
| |
Temperature Coefficient |
±0.03% / °C ( 0 °C~50 °C ) (max.) |
|
| |
Short Circuit Protection |
Auto recovery |
|
| |
|
|
|
|
|
| |
General Specification |
|
| |
Characteristics |
Conditions |
|
| |
Switching Frequency |
100K Hz (typ.) |
|
| |
Isolation Voltage (Input to Output) |
4000 VAC (min.) |
|
| |
Operating Temperature |
-10 °C to +70 °C (with derating) |
|
| |
Storage Temperature |
-25°C to +85°C |
|
| |
Humidity |
95% RH (max.) |
|
| |
Cooling |
Free air convection |
|
| |
|
|
|
|
|
| |
Physical Specification |
|
| |
Characteristics |
Conditions |
|
| |
Dimension (Tolerance ±0.5) |
150.0 x 106.0 x 35.0 mm |
|
| |
6.0 x 4.18 x 1.38 inches |
|
| |
Weight |
615 g |
|
| |
Case Material |
Enclosed |
|
| |
|
|
|
|
|
|
|
|
| Model |
|
|
| |
|
|
| |
|
|
|
|
|
|
| |
|
|
| |
|
|
|
|
|
