CINCONEC6AW-110系列10 w电源转换器EC6AW-110D12 EC6AW-110D15
详细信息
| | 品牌：CINCON | | 加工定制：否 | | 型号：EC6AW-1110D05N EC6AW-110S33N | |
| | 输入电压：DC43-160 V | | 输出电压：DC3.3-15 V | | 输出功率：10 W | |
EC6AW-110系列10 w电源转换器EC6AW-110D12 EC6AW-110D15 EC6AW-1110D05N EC6AW-110S33N
输入电压43 - 160 vdc
10 w输出
43 - 160直流电压输入范围
铁路应用程序
远程开/关
效率为88.5%
在温度保护
在电压/电流保护
连续短路保护
无载功率消耗
与外部电路的EN50155相遇
Model List
| Part Number |
Input Voltage |
Output Voltage |
Output Current |
No load Input Current |
Efficiency (效率) |
I/O Isolation Voltage |
| EC6AW-110S33 |
43~160V |
3.3V |
2.5A |
6mA |
85 |
3000VDC |
| EC6AW-110S05 |
43~160V |
5V |
2A |
6mA |
87 |
3000VDC |
| EC6AW-110S12 |
43~160V |
12V |
0.835A |
6mA |
88 |
3000VDC |
| EC6AW-110S15 |
43~160V |
15V |
0.666A |
6mA |
88.5 |
3000VDC |
| EC6AW-110D05 |
43~160V |
±5V |
±1A |
6mA |
85 |
3000VDC |
| EC6AW-110D12 |
43~160V |
±12V |
±0.416A |
6mA |
87 |
3000VDC |
| EC6AW-110D15 |
43~160V |
±15V |
±0.333A |
6mA |
87.5 |
3000VDC |
| EC6AW-110S33N |
43~160V |
3.3V |
2.5A |
6mA |
85 |
3000VDC |
| EC6AW-110S05N |
43~160V |
5V |
2A |
6mA |
87 |
3000VDC |
| EC6AW-110S12N |
43~160V |
12V |
0.835A |
6mA |
88 |
3000VDC |
| EC6AW-110S15N |
43~160V |
15V |
0.666A |
6mA |
88.5 |
3000VDC |
| EC6AW-110D05N |
43~160V |
±5V |
±1A |
6mA |
85 |
3000VDC |
| EC6AW-110D12N |
43~160V |
±12V |
±0.416A |
6mA |
87 |
3000VDC |
| EC6AW-110D15N |
43~160V |
±15V |
±0.333A |
6mA |
87.5 |
3000VDC |
