| | 品牌：TRACO | | 加工定制：否 | | 型号：TBL090-124 TBL030-112 TBL015-1 | |
| | 输出电流：6 A | | 输入电压：AC85-264V V | | 输出电压：DC5-24 V | |
| | 输出功率：15-150 W | | | | | |
TBL
系列导轨式电源供应器TBL060-124 TBL060-112 TBL150-124 TBL090-124 TBL030-112 TBL015-105
TBL系列是一系列小型DIN导轨安装电源，特别针对建筑和工厂自动化应用而设计。小型低外壳适用于建筑自动化行业中使用的标准化壁挂式控制面板。电源可以在-25°C至+ 60°C的环境温度范围内以满负荷运行，而无需额外的冷却。通用输入电压范围以及适合EMC标准的TBL系列电源适用于市场。
特征
低型箱，模块高度55mm
适用于楼宇自动化中使用的平面控制面板
5功率范围从15到150 W.
通用输入范围85至264 VAC
工作温度范围：-25°C至+ 70°C。
可调输出电压
短路和过载保护
Models
| Order code |
Power |
Output |
|
| TBL015-105 |
12 Watt |
5 VDC / 2400 mA |
|
| TBL015-112 |
15 Watt |
12 VDC / 1250 mA |
|
| TBL015-124 |
15 Watt |
24 VDC / 630 mA |
|
| TBL030-112 |
30 Watt |
12 VDC / 2500 mA |
|
| TBL030-124 |
30 Watt |
|
|
| TBL060-112 |
54 Watt |
12 VDC / 4500 mA |
|
| TBL060-124 |
60 Watt |
24 VDC / 2500 mA |
|
| TBL090-112 |
72 Watt |
12 VDC / 6 A |
|
| TBL090-124 |
90 Watt |
24 VDC / 3750 mA |
|
| TBL150-112 |
120 Watt |
12 VDC / 10 A |
|
| TBL150-124 |
150 Watt |
|
|
ompare
Model
Power
Input
Output
Short description
TBL015-105
12 W
85-264 VAC
5 VDC
(5-5.2 VDC)
15 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL015-112
15 W
85-264 VAC
12 VDC
(12-16 VDC)
15 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL015-124
15 W
85-264 VAC
24 VDC
(24-28 VDC)
15 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL030-112
30 W
85-264 VAC
12 VDC
(12-16 VDC)
30 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL030-124
30 W
85-264 VAC
24 VDC
(24-28 VDC)
30 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL060-112
54 W
85-264 VAC
12 VDC
(12-16 VDC)
60 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL060-124
60 W
85-264 VAC
24 VDC
(24-28 VDC)
60 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL090-112
72 W
85-264 VAC
12 VDC
(12-16 VDC)
90 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL090-124
90 W
85-264 VAC
24 VDC
(24-28 VDC)
90 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL150-112
120 W
85-264 VAC
12 VDC
(12-16 VDC)
150 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
TBL150-124
150 W
85-264 VAC
24 VDC
(24-28 VDC)
150 Watt AC/DC power supply, building automation, 85-264VAC input, 3000 VAC isolation, fits into flat control panels (55 mm depth), DIN-Rail
