| | 品牌：ASTRODYNE | | 类型：AC/DC电源 | | 输入电压：AC85-264V V | |
| | 输出功率：40 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 型号：ASM40-24 ASM40-48 ASM40-12 | | | | | |
ASM40 40 Watt Medical Power Supplies
- Medical Power Supplies: Ten Important Criteria
| |
Up to 40W Output Power |
| |
Universal 90-264VAC Input |
| |
Single and Dual Outputs from 5VDC to 48VDC |
| |
High Efficiency up to 86% |
| |
4000V Isolation |
| |
1U Compatible Height |
| Model Number |
Output Voltage |
Output Amps |
Minimum Load Requirement |
Load Regulation |
Line Regulation |
Cross Regulation |
Ripple and Noise |
Over Current Protection |
Efficiency |
| ASM40-5(A)* |
5VDC |
8 Amps |
0 Amps |
± 1% |
± 1% max |
|
100mV |
170% Self Recovering* |
73% |
| ASM40-9(A)* |
9VDC |
4.44 Amps |
0 Amps |
± 1% |
± 1% max |
|
100mV |
200% Self Recovering* |
82% |
| ASM40-12(A)* |
12VDC |
3.33 Amps |
0 Amps |
± 1% |
± 1% max |
|
150mV |
240% Self Recovering* |
84% |
| ASM40-15(A)* |
15VDC |
2.66 Amps |
0 Amps |
± 1% |
± 1% max |
|
150mV |
240% Self Recovering* |
84% |
| ASM40-24(A)* |
24VDC |
1.66 Amps |
0 Amps |
± 1% |
± 1% max |
|
150mV |
240% Self Recovering* |
86% |
| ASM40-36(A)* |
36VDC |
1.11 Amps |
0 Amps |
± 1% |
± 1% max |
|
100mV |
187% Self Recovering* |
85% |
| ASM40-48(A)* |
48VDC |
0.83 Amps |
0 Amps |
± 1% |
± 1% max |
|
400mV |
240% Self Recovering* |
86% |
| ASM40D-1 |
5/12VDC |
3.3/2 Amps |
0.66/0.40 Amps |
± 3/5% max |
± 1/2% max |
± 3/5% max (100-20% L w. other O/P at 60%) |
100/120mV |
225% Self Recovering* |
81% |
| ASM40D-2 |
5/15VDC |
3.3/1.6 Amps |
0.66/0.32 Amps |
± 3/5% max |
± 1/2% max |
± 3/5% max (100-20% L w. other O/P at 60%) |
100/150mV |
225% Self Recovering* |
82% |
| ASM40D-3 |
5/24VDC |
3.3/1 Amps |
0.66/0.20 Amps |
± 3/5% max |
± 1/2% max |
± 3/5% max (100-20% L w. other O/P at 60%) |
100/240mV |
225% Self Recovering* |
82% |
| ASM40D-5 |
5/48VDC |
3.3/0.50 Amps |
0.66/0.10 Amps |
± 3/5% max |
± 1/2% max |
± 3/5% max (100-20% L w. other O/P at 60%) |
100/400mV |
225% Self Recovering* |
82% |
| |
|
|
|
|
|
|
|
|
|
|
|
ASM40 series
Input Specifications
| Input Voltage Range |
90-264 VAC |
| Frequency Range |
47-63Hz |
| Inrush Current |
30A @ 100VAC Input *; 60A @ 200VAC Input * |
| Leakage Current |
<0.1mA |
Environmental Specifications
| Operating Temperature |
-20 to +50°C(FL) , See Derate |
| EMC |
EN 60601-1-2:2001 |
| Storage Temperature |
-40 to +85°C * |
| Relative Humidity |
0 to + 95%, non-cond * |
| MTBF |
185,000 Hrs, Mil Std 217, 25°C |
General Specifications
| Isolation |
4000VAC |
| Efficiency |
73% |
| Switching Frequency |
65Khz, (fixed, typical) |
| |
|
|
Output Specifications
| Output Voltage |
5VDC |
| Output Amps |
8 Amps |
| Minimum Load Requirement |
Amps |
| Load Regulation |
± 1% |
| Line Regulation |
± 1% max |
| Preset Accuracy |
1% |
| Temperature Coefficient |
± 0.05%/°C |
| Ripple and Noise |
100mV |
| Over Voltage Protection |
Clamp, 118-130% |
| Over Current Protection |
170% Self Recovering* |
| Short Circuit Protection |
Continuous, self-recovering * |
| Hold Up Time |
10 mS, min. |
| DC Voltage Adjust (typ.) |
± 6% of FS (Primary) |
Physical Specifications
| Size (mm) |
50.8 x 101.6 x 30.48mm |
| Size (Inches) |
2” x 4” x 1.2” |
| Construction |
Open Frame |
| Weight (g) |
198g |
| Weight (oz) |
7 oz |
Notes
* These are stress ratings. Exposure of the devices to any of these conditions may adversely affect long term reliability. Proper operation under conditions other than the standard operating conditions is neither warranteed nor implied.
All specifications are typical at nominal input, full load, and 25°C unless otherwise noted
Astrodyne products are not authorized or warranteed for use as critical components in life support systems, equipment used in hazardous environments, nuclear controls systems, or other mission-critical applications. |
