详细信息
品牌：ASTRODYNE 类型：AC/DC电源 输入电压：AC85-264 V 输出功率：15 W 调制方式：脉冲宽度调制（PWM)式 晶体管连接方式：单端式 工作效率：85 % 型号：EFM-1501 EFM-1502 EFM-1503 EFM15 15 Watt Open Frame Power Supplies
EFM15 seriesUniversal 90-264VAC Input High Efficiency Improved EMI Performance 3000V Isolation Single, Dual & Triple Outputs UL60950-1, EN60950-1 Model Number Output Voltage Output Amps Load Regulation Line Regulation Cross Regulation Preset Accuracy Ripple and Noise Efficiency EFM-1500 3.3Volts(DC) 3.5 Amps ±3% (20% FL) ± 0.1~1% 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1501 5vdc 3 Amps ±3% (20% FL) ± 0.1~1% 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1502 12vdc 1.25 Amps ±3% (20% FL) ± 0.1~1% 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1503 15vdc 1 Amps ±3% (20% FL) ± 0.1~1% 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1505 24vdc 0.63 Amps ±3% (20% FL) ± 0.1~1% 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1506 ±12vdc ±0.63 Amps ± 3% (EFM-1508: 0.2/0.2%) (20% FL) ± 0.3~1% (EFM-1508: 0.5/3%) 2% (EFM-1508: 0.5/3%) 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1507 ±15vdc ±0.5 Amps ± 3% (EFM-1508: 0.2/0.2%) (20% FL) ± 0.3~1% (EFM-1508: 0.5/3%) 2% (EFM-1508: 0.5/3%) 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1508 5 / 12vdc 1.8/ 0.8 Amps ± 3% (EFM-1508: 0.2/0.2%) (20% FL) ± 0.3~1% (EFM-1508: 0.5/3%) 2% (EFM-1508: 0.5/3%) 1% (except EFM-1508: 2/5%) 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk 75%~78% (EFM-1508: 74%) EFM-1509 5/ ±12vdc 2.8/±0.13 Amps 0.5/ ±0.2% (20% FL) 0.5/ ±0.3% NA/ ±0.1% 1/ ±5% 50/ ±50mV pk-pk EFM-1509: 70%, EFM-1511: 71% EFM-1511 5/ ±15vdc 2.8/±0.13 Amps 0.5/ ±0.2% (20% FL) 0.5/ ±0.3% NA/ ±0.1% 1/ ±5% 50/ ±50mV pk-pk EFM-1509: 70%, EFM-1511: 71% Input Specifications
Environmental SpecificationsInput Voltage Range 90-264 VAC Frequency Range 47-63 Hz Inrush Current 20A @ 115Volts(DC); 40A @ 230Volts(DC)
General SpecificationsOperating Temperature 0 to +40°C (See Derate) EMC EN55022 Storage Temperature -25 to +71°C * MTBF 559,000 Hrs, Mil Std 217, 25°C Isolation 3000VAC Isolation Input-Ground 2500VAC Isolation Output-Ground 1000VAC Efficiency 75%~78% (EFM-1508: 74%) Switching Frequency 100Khz, (fixed, typical) Safety Approvals UL60950-1, EN60950-1 Output Specifications
Physical SpecificationsOutput Voltage 3.3Volts(DC) Output Amps 3.5 Amps Load Regulation ±3% (20% FL) Line Regulation ± 0.1~1% Preset Accuracy 1% (except EFM-1508: 2/5%) Temperature Coefficient ±0.03%/°C Ripple and Noise 100mV Pk-Pk, typ EFM-1508: 50/50mV pk-pk Over Voltage Protection Clamp Over Temperature Protection Latching, recov after cooling and power restored. Short Circuit Protection Continuous, self-recovering Hold Up Time 20 mS, typ DC Voltage Adjust (typ.) ± 6% of FS (Primary)
NotesSize (mm) 44.95 x 67.05 x 23.11 mm Size (Inches) 1.77” x 2.64” x 0.91” Construction Open Frame Weight (g) 70g Weight (oz) 2.5oz
1. Ripple and Noise depend upon output voltage as specified per particular
All specifications are typical at nominal input, full load, and 25°C unless otherwise noted
Astrodyne products are not authorized or warranteed for use as critical components in life support systems, equipment used in hazardous environments, nuclear controls systems, or other mission-critical applications. -
-
