Input Specifications
Input Voltage Range (Note 8) |
90-264 VAC |
Frequency Range |
47-63Hz |
Inrush Current (115/230 Vin) |
30A / 60A Cold Start, max. |
Input Current (115/230Vin) |
0.8A / 0.4A |
Leakage Current (Safety Class II) |
<0.25mA@240VAC, 50Hz |
Power Factor |
>0.9 at Full Load, 100-230VAC |
Environmental Specifications
Operating Temperature |
-30 to +80°C, See Derate |
Storage Temperature |
+30°C to +85°C, 0~95%RH |
Relative Humidity |
20-90% RH non cond |
MTBF |
150KHrs; Mil-HDBK-217F (25°C) parts Count Method |
Temp. Coefficient |
±0.03%/°C (0~50°C) |
General Specifications
Isolation (I/P-O/P)* |
3KVAC (4242VDC), 60S |
Insulation Resistance |
>100MΩ; 500VDC, 1S 25°C |
Efficiency |
See Selection Chart Above |
EMS |
|
Harmonics |
Compliance to EN6100-3-2 Class C |
ESD |
6100-4-2, contact 6KV, Air 8KV |
RS |
FR: 80MHz - 2.5GHz; 6100-4-3, Field Strength: 3VM |
EFT |
6100-4-4, 2kV on AC power line |
Surge |
6100-4-5, 1kV (L-N) |
CS |
6100-4-6, 3V (EFM) |
DIPS |
6100-4-11, 95% 250Cy, 70% 25Cy, 40% 5Cy, 5% 0.5Cy, Applicable for 240 VAC |
Vibration* |
2G's peak, 10~500Hz, 3 Axes, Period 30 min each along X, Y, Z axes |
Drop Test* |
70cm no damage / carton pakage |
Safety Approvals |
|
|
|
|
Output Specifications
Voltage & Current (Note 3) |
See Selection Chart Above |
Turn On Delay Time |
<2S |
Load Regulation (Note 5 & 7) |
±2% max. |
Line Regulation (Note 5 &6) |
±1% max. |
Over-Shoot & Under-Shoot |
<10% Nominal Voltage, 100-240VAC |
Ripple and Noise (Note 1 & 3) |
See Selection Chart Above |
Over Voltage Protection* |
See Selection Chart Above, Shut down Latch Mode, re-power |
Over Current Protection* |
Hiccup mode, auto recovery after fault condition is removed |
Short Circuit* |
Hiccup mode, auto recovery after fault condition is removed |
Turn On Delay Time |
<2S |
Physical Specifications
Size (Inches) |
1.34" x 1.86" x 4" |
Size (mm) |
34 x 47 x 101.6mm |
Weight (oz) |
4.8oz. |
Weight (g) |
136g |
Notes
* These are stress ratings. Exposure of the devices to any of these conditions may adversely affect long term reliability. Proper operation under conditions other than the standard operating conditions is neither warranteed nor implied.
All specifications are typical at nominal input, full load, and 25°C unless otherwise noted
1. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
2. Constant current adjustable from 70-100% by trim pot.
3. All measurements should be made directly at the output terminals. Operation outside the specified constant current range may cause hiccup resulting in LED blinking or LED dimming.
4. Efficiency is measured at 100-240VAC input incorporated with a constant load.
5. Load/Line regulation measures constant current accuracy.
6. 100-240VAC Input, CC set @ 90% Load.
7. Set CC between 65%-95% load.
8. Derating may be needed at low input voltage. Please check the derating curve for more details.
Astrodyne products are not authorized or warranteed for use as critical components in life support systems, equipment used in hazardous environments, nuclear controls systems, or other mission-critical applications. |
