CINCON260W 微封装开关电源CFM260S240C CFM260S120C
详细信息
| | 品牌：CINCON | | 类型：AC/DC电源 | | 输入电压：AC90-264V V | |
| | 输出功率：260 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC5-48V V | | 工作效率：87 % | | 型号：CFM260S480C CFM260S360C | |
260W CINCON微封装开关电源CFM260S240C CFM260S120C CFM260S480C CFM260S360C
260瓦AC-DC 2 " x4 " ITE开放式框架底板冷却电源
CFM260S
通用输入范围85~264Vac
220W，自然对流
260 w与风扇冷却
2 " x 4 "紧凑的尺寸@CFM260SXXX
空载输入功耗<0.2W
效率93.5%
12 v风机输出
连续短路保护
在温度保护
海拔5000米
| Part Number |
Power (Watts) |
Input Voltage |
Output Voltage |
Output Current |
Efficiency (效率) |
Operating Altitude |
Operating Temperature |
| CFM260S120 |
260.04W |
85-264 |
12V |
21.67A |
92 |
5000m |
-30°C ~ 80°C |
| CFM260S240 |
259.92W |
85-264 |
24V |
10.83A |
93.5 |
5000m |
-30°C ~ 80°C |
| CFM260S360 |
259.92W |
85-264 |
36V |
7.22A |
93 |
5000m |
-30°C ~ 80°C |
| CFM260S480 |
260.16W |
85-264 |
48V |
5.42A |
93.5 |
5000m |
-30°C ~ 80°C |
| CFM260S120B |
260.04W |
85-264 |
12V |
21.67A |
92 |
5000m |
-30°C ~ 80°C |
| CFM260S240B |
259.92W |
85-264 |
24V |
10.83A |
93.5 |
5000m |
-30°C ~ 80°C |
| CFM260S360B |
259.92W |
85-264 |
36V |
7.22A |
93 |
5000m |
-30°C ~ 80°C |
| CFM260S480B |
260.16W |
85-264 |
48V |
5.42A |
93.5 |
5000m |
-30°C ~ 80°C |
| CFM260S120C |
260.04W |
85-264 |
12V |
21.67A |
92 |
5000m |
-30°C ~ 80°C |
| CFM260S240C |
259.92W |
85-264 |
24V |
10.83A |
93.5 |
5000m |
-30°C ~ 80°C |
| CFM260S360C |
259.92W |
85-264 |
36V |
7.22A |
93 |
5000m |
-30°C ~ 80°C |
| CFM260S480C |
260.16W |
85-264 |
48V |
5.42A |
93.5 |
5000m |
-30°C ~ 80°C |
