ARCH稳压电源500W系列ARF500E-12S ARF500E-24S
详细信息
| | 品牌：ARCH | | 加工定制：否 | | 型号：ARF500E-48S | |
| | 输入电压：AC85-264V V | | 输出电压：DC12-48 V | | 输出功率：500 W | |
ARCH
稳压电源500W
系列ARF500E-12S ARF500E-24S ARF500E-48S
500
瓦NEW
封闭式ITE
开关PSU
封闭式开关电源
通用输入范围90-264VAC
紧凑尺寸：5.11 x 3.25 x 2.45
英寸
效率91.5
％
待机5V @ 1A
-30
°C
至+ 80
°C
宽范围工作温度
工作海拔5000M
主动PFC
功能
I / O
绝缘电压4000VAC
三年产品保固
除非另有说明，否则规格均在标称输入电压，+ 25
°C
的预热时间后。
用0.1U 50V // 47U 50V
陶瓷电容测量 交叉输出。
我们保留在不事先通知的情况下对产品材料和规格进行更改的权利，并同意改进可靠性，功能或设计或其他方式。
| Input Specifications / 輸入規格 |
| Voltage |
90~264 VAC or 127~370 VDC |
|
| Frequency |
47-63 Hz |
|
| Inrush Current (<2ms,Cold Start) |
<40 A (115 VAC) /
<80 A (230 VAC) |
(max.) |
| Leakage Current |
<0.1 mA / 264 VAC (Touch Current) |
(max.) |
| |
|
|
| Output Specifications / 輸出規格 |
| Power |
500 |
(max.) |
| Voltage |
12, 24, 48 |
|
| Voltage Adj Range |
±5% Output Voltage |
|
Voltage Accuracy
(Full Load and Nominal Vin) |
±2% |
|
Minimum Load
(at Full Load) |
1% |
|
Line Regulation
(100-264 VAC) |
±1% |
(typ.) |
Load Regulation
(LL to HL at Full Load) |
±1% |
(typ.) |
| Ripple & Noise |
12S:160mV (Vp-p)
---------------------------------
24S:240mV (Vp-p)
---------------------------------
48S:480mV (Vp-p) |
(max.) |
| |
|
|
| Protection / 保護規格 |
| Over Power Protection |
Auto recovery |
| Over Voltage Protection |
Auto recovery |
| Overt Temperature Protection |
Auto recovery |
| Short Circuit Protection |
Protection level 1 (nominal)：
Continuous, Auto recovery
Protection level 2 (instantaneous high current)：
Latch |
| |
|
| Environment Specification / 環境規格 |
| Operating Temperature |
-30 °C to +80 °C |
| Storage Temperature |
-30 °C to +85 °C |
| Temperature Coefficient |
±0.03% / °C ( 0 °C~50 °C )
±0.06% / °C ( -30 °C~0 °C ) |
| Altitude During Operation |
5000m |
| Humidity |
95% RH |
| |
|
| |
|
| SAFETY & EMC |
Isolation Voltage
(Input to Output) |
4000VAC or 5656VDC |
| |
|
| |
|
|
| Others / 其他 |
Dimensions
(Tolerance ±0.5mm) |
129.7 x 82.55 x 62.3 mm
5.11 x 3.25 x 2.45 inches |
| Weight |
710 g |
| Case Material |
Aluminum |
ARF500E-12S
ARF500E-24S
ARF500E-48S
