ARCH700瓦系列开关电源 MQF700C-24S MQF700C-12S MQF700C-28S MQF700C-48S MQF700C-15S
详细信息
| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC85-264V V | |
| | 输出功率：700 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC5-48V V | | 工作效率：86 % | | 型号：MQF700C-28S MQF700C-48S MQF700 | |
700
瓦系列ARCH
开关电源 MQF700C-24S MQF700C-12S MQF700C-28S MQF700C-48S MQF700C-15S
效率92
％
封闭式交换PSU
封闭式医疗开关电源
通用输入范围90-264VAC
，50/60 Hz
超紧凑尺寸：6.7 x 3.66 x 1.61
英寸
远程开/
关功能
待机5V @ 1A
与P.F.C.
功能> 0.9
MQF700C
系列的均流功能
三年产品保固
除非另有说明，否则规格在标称输入电压，预热时间为+ 25
°C
时。
用0.1U 50V // 47U 50V
陶瓷电容测量 交叉输出。
Model No.
(Ordering Part No.) |
Input Range |
Output Voltage |
Output Current |
Eff |
| ( V.AC ) |
( V.DC ) |
( mA ) |
( % ) |
| Single Output Models |
| MQF700C-12S |
90 ~ 264 VAC |
12 |
(at 115 VAC):50,000
(at 230 VAC):52,080 |
89 |
| MQF700C-15S |
90 ~ 264 VAC |
15 |
(at 115 VAC):40,000
(at 230 VAC):41,660 |
90 |
| MQF700C-24S |
90 ~ 264 VAC |
24 |
(at 115 VAC):28,130
(at 230 VAC):29,160 |
91 |
| MQF700C-28S |
90 ~ 264 VAC |
28 |
(at 115 VAC):24,100
(at 230 VAC):25,000 |
92 |
| MQF700C-48S |
90 ~ 264 VAC |
48 |
(at 115 VAC):14,060
(at 230 VAC):14,580 |
92 |
| |
| |
| |
| Input Specifications / 輸入規格 |
| Voltage |
90~264 VAC |
|
| Frequency |
50/60 Hz |
|
| |
|
|
| Output Specifications / 輸出規格 |
| Power |
700 |
(max.) |
| Voltage |
12, 15, 24, 28, 48 |
|
| Voltage Adj Range |
±5% Output Voltage |
|
Voltage Accuracy
(Full Load and Nominal Vin) |
±2% |
|
Minimum Load
(at Full Load) |
1% |
|
Line Regulation
(115-264 VAC) |
±0.5% |
(typ.) |
Load Regulation
(10% to 100% at Full Load) |
±1% |
(typ.) |
| Ripple & Noise |
12S,15S:160mV (Vp-p)
---------------------------------
24S:240mV (Vp-p)
---------------------------------
48S:480mV (Vp-p) |
(max.) |
| Short Circuit Protection |
Auto recovery or Latch |
| Environment Specification / 環境規格 |
| Operating Temperature |
-30 °C to +70 °C |
| Storage Temperature |
-30 °C to +85 °C |
| Temperature Coefficient |
±0.03% / °C ( 0 °C~50 °C )
±0.06% / °C ( -30 °C~0 °C ) |
| Altitude During Operation |
5000m |
| Humidity |
95% RH |
| Atmospheric Pressure |
56 kPa to 106 kPa |
| |
|
| SAFETY & EMC |
Isolation Voltage
(Input to Output) |
4000VAC or 5656VDC |
| Others / 其他 |
Dimension
(Tolerance ±0.5mm) |
170.2 x 93.0 x 41.0 mm
6.7 x 3.66 x 1.61 inches |
| Weight |
890 g |
| Case Material |
Aluminum |
