ARCHMTC系列44-470HZ宽频开关电源MTC-24S MTC-12S MTC-5S12D MTC-5S15D
详细信息
| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC85-264V V | |
| | 输出功率：15W W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC3.3-48 V | | 工作效率：89 % | | 型号：MTC-5S12D MTC-5S15D | |
MTC
系列44-470HZ
宽频开关电源MTC-24S MTC-12S MTC-5S12D MTC-5S15D
经济型15
瓦功能
MTC
系列
紧凑尺寸，2.52 x 1.8 x 0.93
英寸
工作温度：-25~70
度
90~264 VAC
通用输入范围
绝缘电源
监管产出
低纹波和噪声
| |
Model No.
(Ordering Part No.) |
Input Range |
Output Voltage |
Output Current |
Eff |
| ( V.AC ) |
( V.DC ) |
( mA ) |
( % ) |
| Single Output Models |
| MTC-3.3S |
90 ~ 264 VAC |
3.3 |
3000 |
75 |
| MTC-5S |
90 ~ 264 VAC |
5 |
3000 |
79 |
| MTC-7.35S |
90 ~ 264 VAC |
7.35 |
2040 |
79 |
| MTC-9S |
90 ~ 264 VAC |
9 |
1666 |
80 |
| MTC-12S |
90 ~ 264 VAC |
12 |
1250 |
81 |
| MTC-15S |
90 ~ 264 VAC |
15 |
1000 |
82 |
| MTC-24S |
90 ~ 264 VAC |
24 |
625 |
83 |
| |
| Dual Output Models |
| MTC-5D |
90 ~ 264 VAC |
±5 |
±1500 |
79 |
| MTC-12D |
90 ~ 264 VAC |
±12 |
±625 |
82 |
| MTC-15D |
90 ~ 264 VAC |
±15 |
±500 |
82 |
| |
| Triple Output Models |
| MTC-5S12D |
90 ~ 264 VAC |
5 / ±12 |
2000 / ±200 |
78 |
| MTC-5S15D |
90 ~ 264 VAC |
5 / ±15 |
2000 / ±150 |
78 |
| |
|
|
| |
|
|
|
| |
|
Please refer to the PDF file published on the web site as the final version. |
|
| Input Specifications / 輸入規格 |
| Voltage |
90~264 VAC or 120~375 VDC |
|
| Frequency |
47-440 Hz |
|
| |
|
|
| Output Specifications / 輸出規格 |
| Power |
15 |
(max.) |
| Voltage |
3.3, 5, 7.35, 9, 12, 15, 24
---------------------------------
±5, ±12, ±15
---------------------------------
5/±12, 5/±15 |
|
Voltage Accuracy
(Full Load and Nominal Vin) |
Single,Dual:±2%
---------------------------------
Triple:±3% / ±5% |
|
| Short Circuit Protection |
Hiccup mode, indefinite (automatic recovery) |
| |
|
| Environment Specification / 環境規格 |
| Operating Temperature |
-25 °C to +70 °C
(Case Temperature max. +95°C) |
| Storage Temperature |
-40 °C to +85 °C |
| Temperature Coefficient |
±0.01% / °C |
| Altitude During Operation |
5000m |
| Humidity |
up to 95% RH |
| Atmospheric Pressure |
540 hPa to 1060 hPa |
| |
|
| SAFETY & EMC |
Isolation Voltage
(Input to Output) |
4000 VAC |
|
| Others / 其他 |
Dimension
(Tolerance ±0.5mm) |
64.1 x 45.6 x 23.5 mm
2.52 x 1.8 x 0.93 inches |
| Weight |
120 g |
| Case Material |
Plastic resin with Fiberglass
(flammability to UL 94V-0) |
| Cooling Method |
Free air convection |
|
| |
|
|
|
|
|
|
|
