ARCH8W系列开关电源模块 ALC-24S ALC-12S ALC-15S
详细信息
| | 品牌：ARCH | | 加工定制：否 | | 型号：ALC-5S ALC-3.3S ALC-12S5S | |
| | 制作工艺：集成 | | 输出信号：开关型 | | 材料：金属 | |
| | 材料物理性质：导体 | | 材料晶体结构：单晶 | | | |
8W
系列开关电源模块 ALC-24S ALC-12S ALC-15S ALC-5S ALC-3.3S ALC-12S5S
ITE
电源模块
可安装在PCB
上的开关电源模块
密封塑料盒
通用输入范围90-305VAC
，47-440 Hz
紧凑尺寸：1.48 x 1.11 x 1.08
英寸
单和双输出
低纹波和噪音
空载功率<0.3W
隔离等级II
通过CE
和UL
安全认证
三年产品保固
除非另有说明，否则规格在标称输入电压，预热时间为+ 25
°C
时。
用0.1U 50V // 47U 50V
陶瓷电容测量 交叉输出。
Model No.
(Ordering Part No.) |
Input Range |
Output Voltage |
Output Current |
Eff |
| ( V.AC ) |
( V.DC ) |
( mA ) |
( % ) |
| Single Output Models |
| ALC-3.3S |
90 ~ 305 VAC |
3.3 |
2000 |
69 |
| ALC-5S |
90 ~ 305 VAC |
5 |
1600 |
75 |
| ALC-8S |
90 ~ 305 VAC |
8 |
1000 |
78 |
| ALC-9S |
90 ~ 305 VAC |
9 |
888 |
71 |
| ALC-12S |
90 ~ 305 VAC |
12 |
666 |
79 |
| ALC-14S |
90 ~ 305 VAC |
14 |
571 |
80 |
| ALC-15S |
90 ~ 305 VAC |
15 |
533 |
80 |
| ALC-24S |
90 ~ 305 VAC |
24 |
335 |
81 |
| |
| Dual Output Models |
| ALC-5S3.3S |
90 ~ 305 VAC |
5 / 3.3 |
1600 / 310 |
73 |
| ALC-8S5S |
90 ~ 305 VAC |
8 / 5 |
1000 / 100 |
78 |
| ALC-12S5S |
90 ~ 305 VAC |
12 / 5 |
666 / 100 |
79 |
| |
| |
| Input Specifications / 輸入規格 |
| Voltage |
90~305 VAC or 120~430 VDC |
|
| Frequency |
47-440 Hz |
|
| |
|
|
| Output Specifications / 輸出規格 |
| Power |
8 |
(max.) |
| Voltage |
3.3, 5, 8, 9, 12, 14, 15, 24
---------------------------------
5/3.3, 8/5, 12/5 |
Voltage Accuracy
(Full Load and Nominal Vin) |
Single:±2%
---------------------------------
5S3.3S:Vo:±2% / Vr:±15%
--------------------------------
others:Vo:±2% / Vr:±10% |
Minimum Load
(at Full Load) |
Single:0%
---------------------------------
Dual:25% |
Line Regulation
(LL to HL at Full Load) |
Single:±0.2%
---------------------------------
Dual:Vo:±0.2% / Vr:±3% |
(typ.) |
Load Regulation
(S: LL to HL
at Full Load)
(D: LL to HL at Full Load) |
3.3S:±3%
---------------------------------
5S:±2%
---------------------------------
8S~24S::±0.5%
---------------------------------
Dual:Vo:±0.5% / Vr:±5% |
(typ.) |
| Ripple |
24S:<150mV (Vp-p)
---------------------------------
others:<100mV (Vp-p) |
(max.) |
| Noise |
24S:<200mV (Vp-p)
---------------------------------
others:<150mV (Vp-p) |
(max.) |
| Short Circuit Protection |
Hiccup mode,
indefinite (automatic recovery) |
| Environment Specification / 環境規格 |
| Operating Temperature |
-40 °C to +70 °C |
|
| Storage Temperature |
-40 °C to +85 °C |
|
| Temperature Coefficient |
±0.02% / °C |
| Humidity |
95% RH |
|
| |
|
|
| SAFETY & EMC |
Isolation Voltage
(Input to Output) |
3000 VAC |
|
| Others / 其他 |
Dimension
(Tolerance ±0.5mm) |
37.66 x 28.16 x 27.5 mm
1.48 x 1.11 x 1.08 inches |
| Weight |
45 g |
| Case Material |
Plastic resin with Fiberglass
(flammability to UL 94V-0) |
| Cooling Method |
Free air convection |
|
| |
|
|
|
