| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC90-264V V | |
| | 输出功率：15 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC3.3-24 V | | 工作效率：87 % | | 型号：ATCN-12S ATCN-5S | |
15W系列4000VAC绝缘电压电源模块ATCN-24S ATCN-15S ATCN-12S ATCN-5S
ITE
电源模块
可安装在PCB
上的开关电源模块
密封塑料盒
通用输入范围90-264VAC
，50/60 Hz
紧凑尺寸：2.53 x 1.78 x 0.85
英寸
<0.3W
空载输入功率
平均效率（25
％，50
％，75
％，满负载点）
绝缘电压4KV AC
三年产品保固
除非另有说明，否则规格在标称输入电压，满载和预热时间为+ 25
°C
时。
用0.1U 50V // 47U 50V
陶瓷电容测量 交叉输出。
| Input Specifications / 輸入規格 |
| Voltage |
90~264 VAC or 120~370 VDC |
|
| Frequency |
50/60 Hz |
|
| |
|
|
| Output Specifications / 輸出規格 |
| Power |
15 |
() |
| Voltage |
5, 12, 15, 24 |
|
Voltage Accuracy
(Full Load and Nominal Vin) |
±2% |
|
Line Regulation
(LL to HL at Full Load) |
±0.5% |
(typ.) |
Load Regulation
(10% to 100% at Full Load) |
±1% |
(typ.) |
| Ripple & Noise |
5S:100mV (Vp-p)
--------------------------------
12S:120mV (Vp-p)
--------------------------------
15S,24S:200mV (Vp-p) |
(max.) |
| Short Circuit Protection |
Hiccup mode,
indefinite (automatic recovery) |
| Environment Specification / 環境規格 |
| Operating Temperature |
-40 °C to +70 °C |
|
| Storage Temperature |
-40 °C to +85 °C |
|
| Temperature Coefficient |
±0.02% / °C |
| Humidity |
95% RH |
|
| |
|
|
| SAFETY & EMC |
Isolation Voltage
(Input to Output) |
4000 VAC |
|
| Others / 其他 |
Dimension
(Tolerance ±0.5mm) |
64.3 x 45.1 x 21.7 mm
2.53 x 1.78 x 0.85 inches |
| Weight |
92 g |
| Case Material |
Plastic resin with Fiberglass
(flammability) |
| Cooling Method |
Free air convection |
|
| |
ModelNo. |
InputRange |
OutputVoltage |
OutputCurrent |
Eff |
|
| |
(V.AC ) |
(V.DC ) |
(mA ) |
(%) |
|
| |
Single Output Models |
|
| |
ATCN-5S |
90 ~ 264 VAC |
5 |
3000 |
78 |
|
| |
ATCN-12S |
90 ~ 264 VAC |
12 |
1250 |
82 |
|
| |
ATCN-15S |
90 ~ 264 VAC |
15 |
1000 |
81 |
|
| |
ATCN-24S |
90 ~ 264 VAC |
24 |
625 |
82 |
|
| |
|
|
|
|
|
|
|
|
|
