ARCH40W电源模块MSC-24S 12D MSC-5S15D MSC-12S MSC-12D MSC-12S MSC-12D MSC-5S24S
详细信息
| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC90-264V V | |
| | 输出功率：40 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC3.3-24 V | | 工作效率：87 % | | 型号：MSC-12S MSC-12D MSC-5S24S | |
40W电源模块MSC-24S MSC-5S12D MSC-5S15D MSC-12S MSC-12D MSC-5S24S
可安装在PCB
上的开关电源模块
密封塑料盒
通用输入范围90-264VAC
，47-440 Hz
紧凑尺寸：3.5 x 2.5 x 1.06
英寸
调节输出
低纹波和噪音
三年产品保固
除非另有说明，否则所有规格在标称输入电压，满载和预热时间为+ 25
°C
时。
用0.1U 50V // 47U 50V
陶瓷电容测量 交叉输出。
。
| ModelNo. |
InputRange |
OutputVoltage |
OutputCurrent |
Eff |
| (V.AC ) |
(V.DC ) |
(mA ) |
(%) |
| Single Output Models |
| MSC-3.3S |
90 ~ 264 VAC |
3.3 |
8000 |
76 |
| MSC-5S |
90 ~ 264 VAC |
5 |
8000 |
79 |
| MSC-9S |
90 ~ 264 VAC |
9 |
4444 |
82 |
| MSC-12SA |
90 ~ 264 VAC |
12 |
3333 |
83 |
| MSC-15S |
90 ~ 264 VAC |
15 |
2666 |
83 |
| MSC-24S |
90 ~ 264 VAC |
24 |
1667 |
83 |
| |
| Dual Output Models |
| MSC-5D |
90 ~ 264 VAC |
±5 |
±4000 |
80 |
| MSC-12D |
90 ~ 264 VAC |
±12 |
±1666 |
83 |
| MSC-15D |
90 ~ 264 VAC |
±15 |
±1333 |
83 |
| MSC-5S12S |
90 ~ 264 VAC |
5 / 12 |
5000 / 1250 |
81 |
| MSC-5S24S |
90 ~ 264 VAC |
5 / 24 |
5000 / 625 |
80 |
| |
| Triple Output Models |
| MSC-5S12D |
90 ~ 264 VAC |
5 / ±12 |
5000 / ±600 |
79 |
| MSC-5S15D |
90 ~ 264 VAC |
5 / ±15 |
5000 / ±500 |
79 |
| |
| Input Specifications / 輸入規格 |
| Voltage |
90~264 VAC or 100~375 VDC |
|
| Frequency |
47-440 Hz |
|
| |
|
|
| Output Specifications / 輸出規格 |
| Power |
15 |
(.) |
| Voltage |
3.3, 5, 9, 12, 15, 24
---------------------------------
±5, ±12, ±15, 5/12, 5/24
---------------------------------
5/±12, 5/±15 |
|
Voltage Accuracy
(Full Load and Nominal Vin) |
Single,Dual:±2%
---------------------------------
5S12S,5S24S,
Triple:±3% / ±5% |
|
| Environment Specification / 環境規格 |
| Operating Temperature |
-25 °C to +70 °C
(Case Temperature max. +95°C) |
| Storage Temperature |
-40 °C to +85 °C |
| Temperature Coefficient |
±0.01% / °C |
| Altitude During Operation |
5000m |
| Humidity |
up to 95% RH |
| Atmospheric Pressure |
540 hPa to 1060 hPa |
| |
|
| SAFETY & EMC |
Isolation Voltage
(Input to Output) |
4000 VAC |
|
| Others / 其他 |
Dimension
(Tolerance ±0.5mm) |
89.0 x 63.5 x 27.0 mm
3.5 x 2.5 x 1.06 inches |
| Weight |
280 g |
| Case Material |
Plastic resin with Fiberglass
(flammability) |
| Cooling Method |
Free air convection
|
|
| |
|
|
|
