多路输出模块电源EC5C01 EC5C02 EC5C03 EC5C04
详细信息
| | 品牌：CINCON | | 类型：DC/DC电源 | | 输入电压：DC9-36V/18-72 V | |
| | 输出功率：15 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC5/±12V V | | 工作效率：87 % | | 型号：EC5C05 EC5C06 EC5C07 EC5C12 | |
多路输出模块电源EC5C01 EC5C02 EC5C03 EC5C04 EC5C05 EC5C06 EC5C07 EC5C12
15WATT 4
：1
输入DC-DC
转换器
15W
输出
六面金属外壳
效率84
％
远程开/
关
连续短路保护
Model List
| Part Number |
Input Voltage |
Output Voltage |
Output Current |
No load Input Current |
Efficiency (效率) |
I/O Isolation Voltage |
| EC5C11 |
18~72V |
5V |
3A |
10mA |
81 |
500VDC |
| EC5C12 |
18~72V |
12V |
1.25A |
10mA |
83 |
500VDC |
| EC5C13 |
18~72V |
15V |
1A |
10mA |
82 |
500VDC |
| EC5C14 |
18~72V |
±5V |
±1.5A |
15mA |
81 |
500VDC |
| EC5C15 |
18~72V |
±12V |
±0.625A |
15mA |
83 |
500VDC |
| EC5C16 |
18~72V |
±15V |
±0.5A |
15mA |
81 |
500VDC |
| EC5C17 |
18~72V |
5/±12V |
1.5/±0.31A |
15mA |
81 |
500VDC |
| EC5C18 |
18~72V |
5/±15V |
1.5/±0.25A |
15mA |
80 |
500VDC |
| EC5C19 |
18~72V |
3.3V |
3A |
10mA |
77 |
500VDC |
| EC5C01 |
9~36V |
5V |
3A |
15mA |
81 |
500VDC |
| EC5C02 |
9~36V |
12V |
1.25A |
15mA |
84 |
500VDC |
| EC5C03 |
9~36V |
15V |
1A |
15mA |
82 |
500VDC |
| EC5C04 |
9~36V |
±5V |
±1.5A |
20mA |
81 |
500VDC |
| EC5C05 |
9~36V |
±12V |
±0.625A |
20mA |
82 |
500VDC |
| EC5C06 |
9~36V |
±15V |
±0.5A |
20mA |
83 |
500VDC |
| EC5C07 |
9~36V |
5/±12V |
1.5/±0.31A |
20mA |
80 |
500VDC |
| EC5C08 |
9~36V |
5/±15V |
1.5/±0.25A |
20mA |
80 |
500VDC |
| EC5C09 |
9~36V |
3.3V |
3A |
15mA |
78 |
500VDC |
