内置风扇开关电源AQF360F-24S AQF360F-12S
详细信息
| | 品牌：ARCH | | 类型：AC/DC电源 | | 输入电压：AC85-264V/ DC88-370V V | |
| | 输出功率：360 W | | 调制方式：脉冲宽度调制（PWM)式 | | 晶体管连接方式：单端式 | |
| | 输出电压：DC12V--48V V | | 工作效率：92 % | | 型号：AQF360F-48S AQF360F-36S | |
| 内置风扇开关电源AQF360F-24S AQF360F-12S AQF360F-48S AQF360F-36S |
| |
| |
| Feature |
|
|
| |
紧凑尺寸，6.8 x 3.2 x 1.7英寸
包装：附上
工作温度：-10~70度
90~264 VAC通用输入范围
与P.F.C. 功能，PF> 0.95
内置12 VDC风扇冷却
没有风扇的240W对流
保护：过载/过压/过温/短路通过自动恢复
漏电流<300uA
良好的功率密度和效率93％
|
|
| |
| Specification |
| |
1.All specificationsvalid at nominal input voltage,full load and +25°Cafter warm-up time
unless otherwise stated.
2.Measured with 0.1U 50V // 47U 50V Ceramic Cap. Cross to output |
| |
Input Specification |
|
| |
Characteristics |
Conditions |
|
| |
Voltage Range |
AC IN |
90 ~ 264 VAC |
|
| |
DC IN |
120 ~ 370 VDC |
|
| |
Frequency |
47 ~ 63 Hz |
|
| |
|
|
|
|
|
| |
|
|
| |
General Specification |
|
| |
Characteristics |
Conditions |
|
| |
Switching Frequency |
75K Hz (typ.) |
|
| |
Isolation Voltage (Input to Output) |
4000 VAC (min.) |
|
| |
Operating Temperature |
-10 °C to +70 °C (with derating) |
|
| |
Storage Temperature |
-25°C to +85°C |
|
| |
Humidity |
95% RH (max.) |
|
| |
Cooling |
Cooling by Built-in DC FAN |
|
| |
|
|
|
|
|
| |
Physical Specification |
|
| |
Characteristics |
Conditions |
|
| |
Dimension (Tolerance ±0.5) |
172.7 x 81.3 x 42.0 mm |
|
| |
6.8 x 3.2 x 1.7 inches |
|
| |
Weight |
746 g |
|
| |
Case Material |
Enclosed |
|
| |
|
|
|
|
|
|
|
| |
Model |
|
| |
|
|
| |
|
|
| |
| ModelNo. |
InputRange |
OutputVoltage |
OutputCurrent |
Eff |
| (V.AC ) |
(V.DC ) |
(mA ) |
(效率) |
| Single Output Models |
| AQF360F-12S |
90 ~ 264 VAC |
12 |
30,000 |
89 |
| AQF360F-24S |
90 ~ 264 VAC |
24 |
15,000 |
91 |
| AQF360F-36S |
90 ~ 264 VAC |
36 |
10,000 |
92 |
| AQF360F-48S |
90 ~ 264 VAC |
48 |
7500 |
93 |
|
|
|
